T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill

T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill

    • T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill
    • T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill
  • T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill

    Product Details:

    Place of Origin: China
    Brand Name: MIROC Shank Adapter
    Certification: SGS, ISO
    Model Number: Shank Adapter (for Furukawa Drifter)

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 Piece Shank Adapter
    Price: Negotiable
    Packaging Details: Carton Box or Wooden Box
    Delivery Time: 20 days production for shank adapter
    Supply Ability: 20000 pieces per month
    Contact Now
    Detailed Product Description
    Product: Mining Drilling Shank Adapter Diameter: 44.7mm
    Length: 690mm Thread: T38
    Application: Drifting Drilling, Bench Drilling Model: T38 Furukawa HD609 Length 690mm

    T38 Drill Shank Adapter Length 690mm  for Furukawa HD609



    T38 Shank adapter for Furukawa HD 609 length 690mm



    Furukawa HD609

    T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill

    Thread Part Number Length(mm) Diameter(mm) Weight(kg) Flushing Tube(mm)
    T38(1 1/2'') 414832533 690 45 6.3 -
    T45(1 3/'') 414832534 690 45 6.4 -

    90516197, 90510276



    T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill



    Furukawa Shank Adapter Specification



    T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill

    While every component in the drill string is crucial, the shank adapter must be engineered to withstand the most extreme stress. Its function is to transmit impact energy from the rock-drill piston, as well as rotation torque, into the drill string without energy losses. It must withstand and transmit up to 6300 blows per minute from the piston continually, with great endurance and dependability. With this in mind, we manufacture premium quality shank adapters for most brands of the drill machine.



    Shank Adapter for Furukawa Drifter:



    R38 T38 T45 Shank Adapter for Furukawa Drifter HD135/135A

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD150

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD175

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD180

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD190

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD200

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD210

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD260

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD300

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD500

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD606

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD609

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD609RP

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD612

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD612RP

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD615

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD615RP

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD709

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD709RP

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD712

    R38 T38 T45 Shank Adapter for Furukawa Drifter HD712RP



    T38 Drill Shank Adapter Length 690mm Striking Bars For Furukawa HD609 Rock Drill



    Shank Adapter Specification

    Furukawa SHANK ADAPTER
    Furukawa HD 90 Thread Diameter Length Flushing Weight Part Number
    mm mm kg
    R38 40 515 - 4.3 414832528
    Furukawa HD 190 Thread Diameter Length Flushing Weight Part Number
    mm mm kg
    R38 40 500 - 4.5 414832529
    T38 40 500 - 4.5 414832530
    Furukawa HD 300 Thread Diameter Length Flushing Weight Part Number
    mm mm kg
    T38 45 654 16 6.0 414832531
    T45 45 654 16 6.7 414832532
    Furukawa HD 609 Thread Diameter Length Flushing Weight Part Number
    mm mm kg
    T38 45 690 - 6.3 414832533
    T45 45 690 - 6.4 414832534
    Furukawa HD 612 RP Thread Diameter Length Flushing Weight Part Number
    mm mm kg
    T45 51 884 - 11.2 414832535
    Furukawa PD200 Thread Diameter Length Flushing Weight Part Number
    mm mm kg
    T38 45 485 14.3 5.0 414832536
    T45 45 485 14.3 5.4 414832537



    Hydraulic shanks generally have at least a 5 to 14-spline configuration. Pneumatic shanks tend to have internal or through-flushing. They can be identified by their lugs or 4-spline configuration.



    Competitive Advantage

    • High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance.
    • The accurate dimension of thread perfectly matches the rock drill
    • Work reliably and very cost-effective

    Applications



    • Bolting, drifting

    • Bench drilling
    • Production drilling


    We can design and manufacture personalized products to meet your special application, such as changing the length, diameter, etc.
