Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm

Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm

    • Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    • Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    • Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    • Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    • Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    • Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
  • Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm

    Product Details:

    Place of Origin: China
    Brand Name: MIROC Shank Adapter
    Model Number: Shank Adapter

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 Pieces Shank Adappter
    Price: negotiation
    Packaging Details: Carton Box or Wooden Box
    Delivery Time: 20 days
    Payment Terms: L/C, T/T
    Supply Ability: 20000 pieces per month
    Contact Now
    Detailed Product Description
    Name: Shank Adapter Type: Striking Bars
    Model: For COP 1840 Ex Thread: T45 T51
    Application: Mining, Rock Drilling Color: Black

    Shank Adapter For Atlas Copco COP 1840EX Drifter

    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm



    Thread Part Number Length(mm) Diameter(mm) Weight(kg) Flushing Tube(mm)
    T45(1 3/4'') 414832480 770 60 10.8 -
    T51(2'') 414832481 770 60 10.9 -



    Shank adapter ATLAS COPCO COP 1840 extractor T-45,
    length: 770mm, diameter: 60mm,
    equivalent to atlas product No. 90516305, product code 436-13402.10

    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm

    Shank adapter ATLAS COPCO COP 1840 extractor T-51, length: 770mm, diameter: 60mm,

    equivalent to atlas product No. 90516317, product code 437-13402.10
    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm

    In top hammer drilling, the shank adapter transmits impact energy from the piston to the rod(s) or tube(s). Additionally, rotation torque is delivered via the shank adapter.We offer shank adapter ,including R32,R35,R38,T38,T45,T51,T60,ST58,ST68 to compatible to world top brand.Various shanks adapters can be produced according to the samples and the model of rock drill the customer provided.

    Basic Information - KSQ shank adapter equivalent to:

    Atlas Copco, Boart, Furukawa, Gardner-Denver, Ingersoll-Rand, Montabert, SIG, Sandvik Shank Adapter


    Competitive Advantage

    • High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance.
    • The accurate dimension of thread perfectly matches the rock drill
    • Work reliably and very cost-effective

    Applications

    • Bolting, drifting
    • Bench drilling
    • Production drilling


     Specification:


    Shank Adapter for Altas Copco 1840 EX
    Thread Diameter Length Flushing Weight Part Number
    mm mm kg
    T51 60 770   10.9 41482481



    Thread Model of Rock Drill Length(mm) Weight(kg)
    R32 HD120/200,M120 349.3 3.12
    R32 PR123,PR133 349.3 3.12
    R32 Evl130, VL120/140 349.3 3.12
    R38 BBE 51/52/57 448 4.9
    R38 HD120/200,M120 349.3 3.26
    R38 Evl130, VL120/140 349.3 3.26
    R38 VCR260/360 390.5 3.6
    R38 H100 448 4.9
    R38 HL844 448 4.9
    R38 L600 / 750 349.3 3.26
    T38 BBE56/57 530.4 5.5
    T38 COP1036/1038 590 5
    1038ME/1238ME
    T38 HD120/200,M120 349.3 3.4
    T38 PD200 484 3.6
    T38 HPR1H(12 Spline) 725 6.8
    T38 PR123/133/55 349.3 3.4
    T38 ELV130 349.3 3.4
    T38 ELV130 349.3 3.4
    T38 HC80RP (shot) 669 7.9
    T38 VL120/140 349.3 3.4
    T38 VCR260/360 390.5 3.6
    T38 HC80 591 6.68
    T38 HC80RP(Shot) 669 7.9
    T38 HC80RP(Long) 771 8.5
    T38 HL438/538/844 495 3.6
    T38 L600/750 349.3 3.4
    T45 BBE56/57/57-01 530.4 5.7
    T45 Cop1036/1038 590 5
    /1238ME
    T45 HD120/200,M120 349.3 3.6
    T45 HPR1H 12Spline 725 5.7
    T45 PR132 349.3 5
    T45 PR66 558.8 3.6
    T45 EVL130,VL140 349.5 5
    12 Spline
    T45 EVL130, VL120/140 558.8 3.6
    T45 VL671 w 3/4" tube 349.5 5.9
    T45 VL671 w 9/16" tube 533.4 6


    Pictures
    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm

    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm

    KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:

    • Hazardous environment
    • Acts, regulations, and other government guidelines that have to be followed
    • Significant differences in the way people work, mostly due to physical constraints
    • Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.

    Atlas Copco COP 1840 Extractor Drifter Shank Adapter / T45 T51 Drill Bit Adapter Length 770mm
