Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining
Product Details:
Place of Origin: China
Brand Name: MIROC (KSQ)
Certification: ISO
Model Number: DTH Hammer - 110#
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton / Wooden Box or Based on Customer's request
Delivery Time: 10 - 20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 PCS Per Month
Contact Now
Detailed Product Description
Type Of Hammer: DTH-110# Type Of Bit: 838
Diameter, Mm: 110 ~ 150 Working AIr Pressure: 0.5 ~ 0.7 MPa
Drilling Method: DTH Drilling Outer Diameter, Mm: 98
Application: Mining Operations, Quarrying, Tunneling, Water Well Drilling Material: Carbon Steel
Colors: Black, Green, Yellow Or Based On Request
High Light:

down the hole drilling tools

,

down the hole hammer

YS Low Air Pressure DTH Hammer - 110#



Specifications:



Drilling Diameter, mm Length, mm Outer diameter, mm Weight, kg Working Air Pressure, MPa Air consumption, m3/min

Impact power

(N·M)

Number of shocks (times / minute) Connect with drill Rod, the way Connection with the drill bit, the way
110 ~ 150 838 98 30 0.5 ~ 0.7 11 180 >=830 Inside AP12-3/8 φ65-6

Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 0

Description:



In DTH hammers, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH hammers a nearly constant penetration rate regardless of hole length.

  • Small to medium size drilling diameters;
  • Works in low pressure range, capable of drilling shallow to medium hole lengths.

With professional manufacturing experience in DTH hammer production, our factory can supply you with high pressure and medium to low pressure DTH hammers. It strictly matches with API standard and other Chinese industry standards.It is durable for being produced with advanced craftwork and good material.



Specififcations of Different Types of Hammers:



Name  Weight (kg) External Diameter (mm) Connection thread Hole rang (mm) Impact rate Recommended rotation speed
Low air pressure DTH hammer CIR type 5 ~22 50~180 CIR** 55~200 820 rpm
Middle air pressure BR and COP type 10~30 70~110   85~115
3 inch DTH hammer 24.5 81 API 2 3/8” Reg 90~110 28Hz (at 17 bar) 28 r/min
COP34/QL30 etc
4 inch DTH hammer 39.2 99 API 2 3/8” Reg 110~150 27Hz (at 17 bar) 25~40 r/min
COP44/DHD340 etc
5 inch DTH hammer 71.5 125 API 2 3/8” or API 3 1/2” Reg 135~165 25Hz (at 17 bar) 20~30 r/min
COP54/Mission50 etc
6 inch DTH hammer 98 142 API 3 1/2” Reg 152~216 23Hz (at 17 bar) 15~25 r/min
COP64/QL60 etc
8 inch DTH hammer 188 180 API 4 1/2” Reg 203~305 20Hz (at 17 bar) 15~20 r/min
COP84/SD8 etc



Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 1Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 2



Advantages:



1. Deliver maximum energy to drilling bit, fast drilling speed and low air consumption due to the special inner structure of HD series DTH hammer designed according to newest rock drilling theory.

2. Smooth performance and long service life of HD series DTH hammer due to high quality alloy steel materials and advanced processing technology adapted.

3. Low problem rate and easy to maintenance due to simple, reliable and easy assemble and disassemble inner structure of hammer.

4. Easy to depart bit from hammer due to multi—head thread connecting chuck and cylinder of hammer.

5. Interchangeable with DTH bit and drill pipe.

6. Main hammer components manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment.



Available for all working conditions, high performance in overburden and water well drilling projects.



Application:

  • Blast hole
  • Water well
  • Environmental
  • Exploration
  • Construction





Real photos from the factory:



Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 3

Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 4

Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 5

Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 6



FAQ:

Q: What methods of payment are accepted?
A: We work with T/T, L/C, AliBaba, Paypal, West Union, Money Gram.
Q: Can we select the color of the products?
A: Yes, sure. Either you can choose the color among our standards or we can make it exactly according to your requirements.
Q: Can we use our company's logo on your products?
A: Yes, we can be OEM Company for you.
Q: What's your delivery time?
A: It depends on the quantity of your order, but normally the manufacture time is around 10-20 days. And the delivery time depends on the way of shipment (by air/by sea). We always advice you the best way of delivery use the individual approach according to your requirements.
Q: What about the shipment?
A: It's based on the product type and the order quantity. We use carton or wooden box (also we can follow your reqirements) ans we can send it to you by Air or by Sea, either send the products to your Chinese agent.
Q: How to control the quality?
A: We always carefully check all the details before shipment, we are always online with you if any questions. Your satisfaction with our products is one of our main aims. We can send all the prooves if any questions.
Q: Do you offer sample order?
A: Yes, we welcome you to order some samples for testing our quality. For cheching the quality it's need only 1-2 samples to understand our really high quality and be sure in our production.
Q: Do you have after-sale service and warranty period?
A: Yes, of course. We offer our clients after-sale maintenance, technical support and warranty. If any questions or problems, please contact us asap and we will reply you within 24 hours.
Q: Do you have any social network to follow your updates?
A: We have:
Instagram: ksq_tech;
Twitter: @KsqCo - KSQ Technologies (Beijing) Co. Ltd.
Facebook: KSQ Technologies
YouTube: in the search box type KSQ Technologies and you will find some videos of our work.



P.S. Our company has been certificated by Chinese government, and verified by Alibaba Trade Assurance, 100% refund of the Trade Assurance Amount. Alibaba can guarantee all of your payment, you don't need to worry about it, everything is controlled by world corporations. We are fair with our customers and do our best to be reliable company for you!





MIROC® Production:
Integral Rods

Plug Hole Rods
Tapered Drilling Tools
Extension Drilling Tools
Drifting and Tunneling Tools
Reaming Tools
Shank Rods
Coupling Sleeves
Shank Adapters (Striking Bars)
Down-the-hole (DTH) Bits
Down-the-hole (DTH) Hammers

Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 7Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 8

Low Air Pressure Down The Hole Drilling Tools Hammer For Tunneling Mining 9



Company Information:

DTH Drill Bit 127mm DHD340 Bit Shank With Spherical and Ballistic Carbide Have Foot Valve


The MIROC® Rock Drilling Tools product line by KSQ Technologies (Beijing) Co.Ltd. is the result of years of advanced engineering, precision manufacturing, and dedication to the use of high-quality materials.
MIROC® Rock Drilling Tools are used by many drilling professionals related to mining, construction, tunneling, and quarrying projects around the globe.



We take pride in being the only manufacturers in China that has a diverse line of DTH bits that range from 3"-47"(76mm~1200mm) in diameter with most the leading hammer shanks.



Made from high quality alloy steel and advanced heat-treatment, our bits are ensured extreme protection against wear and fatigue. They're also available in four different bit-head designs - Convex, Flat, Concave and Drop center face, and four different inserts-Spherical,Ballistic,Semi-ballistic,Two-Step to tackle any challenge and rock formations.
