    Product Details:

    Place of Origin: China
    Brand Name: MIROC (KSQ)
    Certification: ISO
    Model Number: DTH Drill Pipes

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PCS
    Price: USD50-USD1000
    Packaging Details: Carton / Wooden Box or Customized
    Delivery Time: 10 - 20 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20000 PCS Per Month
    Contact Now
    Detailed Product Description
    Machine Type: Down The Hole Drilling Tools Name Of The Product: DTH Drill Pipe
    Length, Mm: 1000 - 6000 Type Of Thread: API Reg Thread / F Thread
    Connection: Connected With DTH Hammers Wall Thickness: 4.5mm, 5.5mm, 6.5mm
    Application: Water Well Drilling, Quarry Drilling, DTH Drilling Colors: Black Or Customized
    Material: Carbon Steel
    High Light:

    rock drill tools

    ,

    down the hole drilling tools

    Down The Hole Drilling Tools

     DTH Drill Pipes

    Length: 1000mm - 6000mm



    Description:

    In DTH drilling, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH drilling a nearly constant penetration rate regardless of hole length.DTH drilling enables drillers to reach hole depths that are double of what top hammer drilling can do. This is possible with the use of DTH Pipes and DTH Subs.



    Drill pipe is a major drill component which connects rotary system,hoisting system,circulation system with drill collar and bit.Through it the rotary table drives the bit rotation,hook drives bit up and down and drill fluid flows to the bottom forming circle to make the bit breaks rock and reaches continuous drilling.



    Down th hole drill pipes play a significant role in all DTH drilling, regardless of application, rock type, hole depth or drill rig. The key features of a high quality DTH tube are durability, accuracy and manageability. KSQ DTH drill pipes are made of superior alloy and the both thread ends are friction welded to the seamless steel pipe.The high pressure air is delivered to DTH hammer by DTH drill pipe, simultaneously it transfers the rotation and press force to the DTH hammer.

    Down The Hole Drilling Tools For Water Well Drilling DTH Drill Pipes API Regular Thread / F Thread
    API REGULAR THREAD
    Outer diameter Thread Wall thickness Length Wrench flat Weight
    mm inch mm inch mm foot mm inch kg
    76 3 2 3/8 API Reg 5.5 2/9 1000 3 2/7 57 2 1/4 17
    76 3 5.5 2/9 1500 5 57 2 1/4 22
    76 3 5.5 2/9 2000 6 5/9 57 2 1/4 26
    76 3 5.5 2/9 3000 9 5/6 57 2 1/4 35

    76 3 2 3/8 API Reg

    5.5

    2/9 1000 3 2/7 65 2 5/9 17
    76 3 5.5 2/9 1500 5 65 2 5/9 22
    76 3 5.5 2/9 2000 6 5/9 65 2 5/9 26
    76 3 5.5 2/9 3000 9 5/6 65 2 5/9 35

    76 3 2 3/8 API Reg 6.5 1/4 3000 9 5/6 65 2 5/9 46
    76 3 6.5 1/4 4500 14 3/4 65 2 5/9 56
    76 3 6.5 1/4 6000 19 2/3 65 2 5/9 73

    89 3 1/2 2 3/8 API Reg 5.5 2/9 1000 3 2/7 65 2 5/9 20
    89 3 1/2 5.5 2/9 1500 5 65 2 5/9 25
    89 3 1/2 5.5 2/9 2000 6 5/9 65 2 5/9 30
    89 3 1/2 5.5 2/9 3000 9 5/6 65 2 5/9 40

    89 3 1/2 2 3/8 API Reg 6.5 1/4 1000 3 2/7 65 2 5/9 21
    89 3 1/2 6.5 1/4 1500 5 65 2 5/9 26
    89 3 1/2 6.5 1/4 2000 6 5/9 65 2 5/9 32
    89 3 1/2 6.5 1/4 3000 9 5/6 65 2 5/9 45
    89 3 1/2 6.5 1/4 4500 14 3/4 65 2 5/9 65
    89 3 1/2 6.5 1/4 6000 19 2/3 65 2 5/9 84
    F THREAD
    Outer diameter Thread Wall thickness Length Wrench flat Weight
    mm inch mm inch mm foot mm inch kg
    50 2 F42×10 4.5 1/6 1000 3 2/7 40 1 5/8 -
    60 2 3/8 F48×10 4.5 1/6 1000 3 2/7 40 1 5/8 -
    60 2 3/8 F48×10 4.5 1/6 1500 5 40 1 5/8 -
    60 2 3/8 F48×10 4.5 1/6 2000 6 5/9 40 1 5/8 -
    60 2 3/8 F48×10 4.5 1/6 3000 9 5/6 40 1 5/8 -



    Competitive Advantage:

    High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance.



    Application:

    • DTH Drilling
    • Quarry Drilling
    • Water well drilling

    Underground mining
