Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength

Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength

    • Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength
    • Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength
  • Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength

    Product Details:

    Place of Origin: China
    Brand Name: MIROC Shank Adapter
    Model Number: Shank Adapter (for Drifter)

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 Piece Shank Adapter
    Price: Negotiable
    Packaging Details: Carton Box or Wooden Box
    Delivery Time: 25 days
    Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 20000 pieces per month
    Contact Now
    Detailed Product Description
    Product: Shank Adapter Diameter: 32mm 38mm 44mm 64mm 80mm
    Length: 380mm 500mm 711mm Thread: R32 R38 T38 T45 T51 ST58 ST68
    Color: Black Weight: 4.3kg-16.3kg

    Drilling Rig for Bench drilling, longhole dr Drill Shank Adapter Atlas Copco R32 R38 T38 Thread For COP / BBC / BBE



    Atlas Copco COP 1036, COP 1038, COP 1238



    Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength

    Thread Product No. Product code Length
    (L) mm
    Dia
    (D) mm
    Weight
    approx. kg
    Flushing
    tube mm
    R32 (1¼") 90515888 403-03003,10 575 38 4.6 /
    R38 (1½") 90515899 404-03003,10 575 38 4.7
    T38 (1½") 90515981 435-03003,10 575 38 4.9
    T45 (1¾") 90515996 436-03003,10 575 45 5.8
    R32 (1¼") 90515889 403-03003-13,10 575 45 5.2
    TC35 (13⁄8") 90516341 469-03003-13,10 575 45 5.4
    R38 (1½") 90515900 404-03003-13,10 575 45 5.4
    T38 (1½") 90515982 435-03003-13,10 575 45 5.4



    Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength

    Description
    In top hammer drilling, the shank adapter transmits impact energy from the piston to the rod(s) or tube(s). Additionally, rotation torque is delivered via the shank adapter.

    • Used in top hammer drilling systems



    Shank adapter equivalent to:

    • Atlas Copco shank adapter
    • Boart shank adapter
    • Furukawa shank adapter
    • Gardner-Denver shank adapter
    • Ingersoll-Rand shank adapter
    • Montabert shank adapter
    • SIG shank adapters
    • shank adapter

    shank adapter | adaptador de la espiga | adaptador de cabo | Adaptateur à tige | Schaft -Adapter | sap adaptörü | per gambo | sovituskantaan | nackadapter | nakkeadapteren | adapter cholewka | adapter shank



    Applications

    • Underground mining
    • Tunneling
    • Quarry

    Competitive Advantage

    High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance

    Underground Mining Drill Shank Adapter R32 R38 T38 Thread High Strength
