| Place of Origin: | China |
| Brand Name: | MIROC |
| Model Number: | 4148301054-4148301060 |
| Minimum Order Quantity: | 50 |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden Plate |
| Delivery Time: | 25 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 20000 pieces per month |
| High Light: | drill bit shank adapter,threaded shank drill bit adapter |
||
|---|---|---|---|
Description
In top hammer drilling, the shank adapter transmits impact energy from the piston to the rod(s) or tube(s). Additionally, rotation torque is delivered via the shank adapter.
• Used in top hammer drilling systems
Color: Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: Atlas Copco Shank Adapters
Applications
• Underground mining
• Tunneling
• Quarry
Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
specification
<
| Part Number | Product Code and Brief Description | Thread | Length (mm) | Weight (kg) |
| COP 1032 | ||||
| 4148301054 | COP 1032 [G1] | R32 | 550 | 5.3 |
| 4148301055 | COP 1032 [G2] | R35 | 550 | 5.6 |
| 4148301056 | COP 1032 [G3] | R38 | 550 | 5.7 |
| 4148301057 | COP 1032 [G4] | T38 | 550 | 5.7 |
| COP 1036, COP 1038HB | ||||
| 4148301058 | COP 1036, COP 1038HB [G1] | R32 | 500 | 4.3 |
| 4148301059 | COP 1036, COP 1038HB [G2] | T38 | 500 | 4.7 |
| 4148301060 | COP 1036, COP 1038HB [G3] | T45 | 500 | 5.3 |
