| Place of Origin: | China |
| Brand Name: | MIROC |
| Model Number: | 4148300579-4148300647 |
| Minimum Order Quantity: | 50 |
|---|---|
| Price: | negotiation |
| Packaging Details: | Carton Box or Wooden Box |
| Delivery Time: | 25 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 20000 pieces per month |
| Material: | Tungsten Carbide And High Strength Alloy Steel | Color: | Based On Customer Requirements |
|---|---|---|---|
| Type: | T51 | Processing: | CNC Milling And Proprietary Heat Treatment Process |
| High Light: | crossover coupling,threaded coupling |
||
Tungsten Carbide T51 Drill Coupling for Rock Drilling Tool
Quick Detail
• T51 thread system
• Widely used in drifting, tunneling, benching, and long hole drilling
Applications
• Underground mining
• Tunneling
• Quarry
Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
specification
| Part Number | Product Code and Brief Description | Length (mm) | Length (inch) | Diameter (mm) | Diameter (inch) | Weight (kg) |
| T51 Standard Coupling | ||||||
| 4148300961 | CS71-T51-225, T51 Standard Coupling | 225 | 8 6/7 | 71 | 2 4/5 | 4.6 |
| 4148300962 | CS76-T51-225, T51 Standard Coupling | 225 | 8 6/7 | 76 | 3 | 4.8 |
| 4148300963 | CS72-T51-235, T51 Standard Coupling | 235 | 9 1/4 | 72 | 2 5/6 | 4.7 |
| 4148300964 | CS77-T51-235, T51 Standard Coupling | 235 | 9 1/4 | 77 | 3 | 4.9 |
