R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits

R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits

    • R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits
    • R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits
    • R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits
    • R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits
  • R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits

    Product Details:

    Place of Origin: Shan Dong, China(Mainland)
    Brand Name: MIROC
    Certification: API / GB
    Model Number: Thread Button Bit R25/R32/R38/T38/T45/T51/ST58/ST68/GT60

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: Carton or Wooden Box
    Delivery Time: 1-20 days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 5000 pieces per month
    Contact Now
    Detailed Product Description
    Material: 45CrNiMoV Processing Type: Forging
    Use: Rock Drill/tunneling/underground Construction/quarry Shape: According To The Needs
    Advantage: OEM Color: Green/Black/Yellow ETC.



    R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits



    Tungsten carbide drill rock bit



    1) tungsten carbide drill rock bit is made with best quality alloy steel bar and tungsten carbide buttons, through special heat treatment.
    2) tungsten carbide drill rock bit is suitable for all kinds of rock—Soft rock, loose-medium rock, hard rock and any other special formations.
    3) tungsten carbide drill rock bit is divided into planar and concave heart-shaped, easy return type, easy to return to the concave heart-type.

    4) tungsten carbide drill rock bit is equipped with rock drilling machines.

    5)Our products are exporting to Middle East, South Africa, Europe, South Asia, Southeast Asia,etc.

    6) tungsten carbide drill rock bit can be made as customers’ requirements.



    Specifications

     1) Thread connection: R22, R25, R28, R32, R38, T38, T45, T51, ST58, ST68, GT60 .
    2) Steel material: 45CrNiMoV.
    3) Suitable carbide tips.
    4) Bits diameter: 30-127mm.




    Usage:drilling in ore field,

             suitable even for harsh enviroment works;

    Selling Point: Quality certified;

                    Competitive prices;

                    Brand Name effect;

                    Nice after-sales services;



    T51 button bit


      Bit Dia. Buttons and Size (mm) Flushing Hole Weight
      mm Front Gauge Front  Side kg
    1 89 3x11, 2x11 6x13 4  - 4.9
    2 102 3x13, 2x13 6x14 3 1 5.2
    3 115 6x14  8x14 2  - 6.8
    4 127 4x16, 2x13 8x16 4  - 7.5
    T45 button bit
      Bit Dia. Buttons and Size (mm) Flushing Hole Weight
      mm Front Gauge Front  Side kg
    1 70 3×11, 1×19  6×11 3  - 2.2
    2 76 3×11,  1×11  6×13 3  - 2.4
    3 89 3×11,  2×11  6×13 3 1 4.1
    4 102 3×13,  2×13  6×14 3 1 4.5
    T38 button bit
      Bit Dia. Buttons and Size (mm) Flushing Hole Weight
      mm Front Gauge Front  Side kg
    1 64 3×10, 1×10  6×11 3  - 1.7
    2 70 3×10, 1×10  6×12 3  - 1.8
    3 76 3×11, 1×11  6×12 3 1 2.6
    4 89 3×11, 2×11  6×13 3 1 3.3
    R38 button bit
      Bit Dia. Buttons and Size (mm) Flushing Hole Weight
      mm Front Gauge Front  Side kg
    1 64 3×11  6×12 3  - 1.8
    2 70 3×10, 1×10  6×12 3  - 1.8
    3 76 3×11, 1×11  6×12 2  - 2.6
    4 89 4×13, 1×13  8×13 4  - 3.3
    R32 button bit
      Bit Dia. Buttons and Size (mm) Flushing Hole Weight
      mm Front Gauge Front  Side kg
    1 41 2×8  5×9 1 1 0.7
    2 43 2×9  5×10 1 1 0.7
    3 45 2×9  5×11 1 1 0.8
    4 48 2×9  5×11 1 1 0.9
    5 51 2×10  5×11 1 1 1
    6 57 3×9 6×11 3  - 1.3
    7 64 3×11  6×12 3  - 1.6
    8 70 4×11  8×11 2  - 2.6
    9 76 4×11 8×11 2  - 2.8
    R28 button bit
      Bit Dia. Buttons and Size (mm) Flushing Hole Weight
      mm Front Gauge Front  Side kg
    1 37 2×7  5×9 1 1 0.5
    2 38 2×7  5×9 1 1 0.6
    3 41 2×8 5×9 1 1 0.7
    4 43 2×9 5×9 1 2 0.8
    5 45 2×9 5×10 1 2 0.9
    6 48 2×9  5×11 1 2 1
    R25 button bit
      Bit Dia. Buttons and Size (mm) Flushing Hole Weight
      mm Front Gauge Front  Side kg
    1 33 2x7  5x7 1 1 0.4
    2 35 2x7 5x8 1 1 0.4
    3 38 2x7 5x8 1 1 0.5
    4 41 2x8 5x9 1 2 0.6
    5 45 2x8 5x10 1 2 0.6



    R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits

    R25 / T51 Button Drill Bit Diameter 64 - 152mm Ballistic Rock Drilling Bits
