MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity

MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity

    • MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity
    • MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity
  • MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity

    Product Details:

    Place of Origin: China
    Brand Name: ROXMECH
    Certification: API/CE Certificate
    Model Number: MT30D Low Profile Dump Truck

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set Low Profile Dump Truck
    Price: negotiation
    Packaging Details: Nude Package or Based on Customer's Requirements
    Delivery Time: 1-3 Months
    Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability: 3pcs per month
    Contact Now
    Detailed Product Description
    Material: Tungsten Carbide And High Quality Carbon Steel Use: Tunneling, Mining, Quarrying, Construction
    Processing Type: CNC Milling And Proprietary Heat Treatment Process

    MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity



    Describtion



    The MT30D Low Profile Dump Truck is a collaorative effort with The Rock Engineering Inc. based in Atlanta, USA. The MT30D is designed from the ground up for large size rock excavation operations that require high haulage productivity. Being MSHA and MDG-15 compliant, it's ready to tackle many miming and tunneling projects around the world.



    specification


    MT30D Low Profile Dump Truck Main Dimensions
    Length 10150mm
    Width1804 2700mm
    Height 2600mm
    Turning Radius 5137mm(Inside)
    8700mm(Outside)
    Volume Capacity 16m³
    Tramming Capacity 33000kg
    Engine CUMMINS QSX15 (Tier 3) turbocharged water cooled  diesel engine
    Torque Converter DANA CL8000
    Transmission DANA R6000
    Axles KESSLER D91
    Tires 26.50-25.00 E4



    MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity

    MT30D Heavy Duty Low Profile Dump Truck With 16.5m3 and 33000kg Capacity



    Applications

    •  Underground Mining

    •  Hydropower Tunneling

    •  Roadway/Railway Tunneling

    •  Can be utilized as a multi-role equipment with various attachments (i.e. shotcrete robot arm)


    Competitive Advantage

    •  Major components from industry respected suppliers

    •  Simple yet very robust design

    •  Very competitive pricing compared to its counterparts coming from well-known brands

    •  Competitive delivery

    •  Engineers available to service machinery overseas



    Our Services

    ROXMECH® was developed through years of exchanges and hands-on work with mining
    operations in China and some parts of the world where mining is the lifeblood of the econ-
    omy. In every product we build, our reputation and experience can be seen. That’s the rea-
    son to choose us if you are looking to improve your productivity and reduce costs.



    Company Information

    KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations.
