Home ProductsButton Drill Bit

Quarry tapered button drill bit , SGS 6 degree button bits rock drilling

Quarry tapered button drill bit , SGS 6 degree button bits rock drilling

    • Quarry tapered button drill bit , SGS 6 degree button bits rock drilling
    • Quarry tapered button drill bit , SGS 6 degree button bits rock drilling
    • Quarry tapered button drill bit , SGS 6 degree button bits rock drilling
  • Quarry tapered button drill bit , SGS 6 degree button bits rock drilling

    Product Details:

    Place of Origin: China
    Brand Name: MIROC
    Certification: SGS
    Model Number: Tapered button bit

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Price: negotiation
    Packaging Details: Wooden box
    Delivery Time: 15-20days
    Payment Terms: T/T, L/C, D/A, D/P, Western Union
    Supply Ability: 30000pieces per month
    Contact Now
    Detailed Product Description

    Quarry tapered button drill bit , SGS 6 degree button bits rock drilling





    What can you get from KSQ?

    1. Good service for the products purchased
    2. Good quality control of products produced
    3. Reasonable prices for the products offered
    4. Best advices based on the experience and knowledge of well know what to do and how to do


    Product Description



    Tapered button quarry drill bit


    Bit diameter: 32mm to 42mm

    Body height: 50mm, 55mm,60mm

    Taper/Grade: 6 degree, 7 degree, 11 dregree, 12 degree

    Shank Diameter: for Hex22 tapered rod





    Taper button bit - For 22 mm (7⁄8") hex. Rod
    Quarry tapered button drill bit , SGS 6 degree button bits rock drilling Bit Diameter mm 32 33 34 35 36 38 40 42
    inch 1 1/4 1 2/7 1 1/3 1 3/8 1 3/7 1 1/2 1 4/7 1 2/3
    Quarry tapered button drill bit , SGS 6 degree button bits rock drilling Tungsten Carbide Button Number 4, 6, 7
    Taper/Grade 6,7,11,12 degree



    Part Number Bit Diameter

    Tungsten Carbide Button

    (No. x mm)

    (mm) (inch) Front Buttons Gauge Buttons
    4148300157 32 1 1/4 1x8 3x8
    4148300158 33 1 2/7 2x7 5x7
    4148300159 34 1 1/3 2x7 4x7
    4148300160 35 1 3/8 2x7 5x8
    4148300161 36 1 3/7 1x8 3x9
    4148300162 36 1 3/7 2x7 5x8
    4148300163 38 1 1/2 1x8 3x9
    4148300164 38 1 1/2 2x7 5x8
    4148300165 38 1 1/2 2x7 5x9
    4148300166 40 1 4/7 1x8 3x9
    4148300167 40 1 4/7 1x9 3x10
    4148300168 40 1 4/7 1x9 3x9
    4148300169 40 1 4/7 2x7 5x9
    4148300170 42 1 2/3 1x8 3x9
    4148300171 42 1 2/3 1x9 3x10
    4148300172 42 1 2/3 1x9 3x9
    4148300173 42 1 2/3 2x8 5x9



    drill bit | broca | broca | foret | Bohrer | matkap ucu | punta da trapano | boorpunt | jesie | boret drill bit | broca | broca | foret | Bohrer | matkap ucu | punta da trapano | boorpunt | jesie | boret tapered tungsten carbides knock off drill bit
