Home ProductsIntegral Drill Rod

Chisel Tungsten Carbide Tips Steel Integral Drill Rod

Chisel Tungsten Carbide Tips Steel Integral Drill Rod

  • Chisel Tungsten Carbide Tips Steel Integral Drill Rod
  • Chisel Tungsten Carbide Tips Steel Integral Drill Rod
  • Chisel Tungsten Carbide Tips Steel Integral Drill Rod
Chisel Tungsten Carbide Tips Steel Integral Drill Rod
Product Details:
Place of Origin: China
Brand Name: MIROC
Certification: SGS Certification
Model Number: Integral Rod with Chisel Bit
Payment & Shipping Terms:
Minimum Order Quantity: 20pcs
Price: negotiation
Packaging Details: Wooden box
Delivery Time: 20-25days
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 30000 Per Month
Contact Now
Detailed Product Description
Color:: Black Material: Hollow Steel Rod With Chisel Tungsten Carbide
Application: Tunnel, Quarry, Bench Rock Drilling Material:: Forge
Type:: Drill Rod Machine Type:: Machine Drilling Tools
High Light:

stone drilling tools

,

integral drill rods

Chisel Tungsten Carbide Tips Steel Integral Drill Rod

KSQ Beijing Integral Rod with Hex22x108mm Shank For Mining
Bit diameter: 26mm, 28mm, 30mm, 32mm, 34mm, 36mm, 38mm, 40mm, 42mm
Legnth: 400mm to 8000mm
Shank: Hex22x108mm, Hex19mmx108mm, Hex25mmx159mm

Chisel Tungsten Carbide Tips Steel Integral Drill Rod 0

Hex19mm

Length Bit dia. Weight approx kg
mm foot
400 1'4" 29 1.3
500 1'8" 29 1.5
800 2'7" 28 2.2
1000 3'3 3/8" 28 2.6
1200 3'11" 27 3.0
1600 5'3" 27 3.9
2400 7'10" 26 5.7
3200 10'6" 25 7.5
4000 13'1" 24 9.2
400 1'4" 24 1.3
800 2'7" 23 2.2
600 2' 27 1.7
1200 3'11" 26 3.0
2000 6'7" 24 4.8
2400 7'10" 24 5.7
2700 8'10" 24 6.3
400 1'4" 25 1.3
800 2'7" 34 2.2





Hex22

Lenght Bit dia. Weight approx kg
mm foot
800 2'7" 34 3.0
1600 5'3" 33 5.2
2400 7'10" 32 8.0
3200 10'6" 31 10.2
4000 13'1" 30 12.9
4800 15'9" 29 15.1
5600 18'4" 28 17.6
6400 21' 27 20.1
7200 23'6" 26 22.5
800 2'7" 40 3.0
1600 5'3" 39 5.2
2400 7'10" 38 8.0
3200 10'6" 37 10.2
4000 13'1" 36 12.9
4800 15'9" 35 15.1
5600 18'4" 34 17.6
6400 21' 33 20.1
7200 23'6" 32 22.5
8000 26'2" 31 25.0
400 1'4" 34 1.7
800 2'7" 33 3.0
1200 3'11" 32 4.1
1600 5'3" 31 5.2
2000 6'7" 30 6.7
600 2' 41 2.4
1200 3'11" 40 4.3
1800 5'11" 39 6.2
2400 7'10" 38 8.0
400 1'4" 41 1.7
800 2'7" 29 3.0
800 2'7" 38 3.1
1200 3'11" 39 4.3
1600 5'3" 36 5.2
1800 5'11" 36 6.0
2000 6'7" 32 6.7
2400 7'10" 27 8.0
3200 10'6" 27 10.2
3200 10'6" 32 10.3
6400 21' 30 20.1
8000 26'2" 26 25

drill rod | la barra de taladro | broca Rod | forer tige | Bohrgestänge | çubuk matkap | drill rod hard rock Mining Integral drill steel,Integral drill rod

Chisel Tungsten Carbide Tips Steel Integral Drill Rod 1



Chisel Tungsten Carbide Tips Steel Integral Drill Rod 2Chisel Tungsten Carbide Tips Steel Integral Drill Rod 3Chisel Tungsten Carbide Tips Steel Integral Drill Rod 4Chisel Tungsten Carbide Tips Steel Integral Drill Rod 5Chisel Tungsten Carbide Tips Steel Integral Drill Rod 6Chisel Tungsten Carbide Tips Steel Integral Drill Rod 7
