DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3

DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3

    • DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3
    • DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3
    • DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3
    • DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3
  • DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3

    Product Details:

    Place of Origin: China
    Brand Name: ROXMECH
    Certification: CE, ISO
    Model Number: RL-3 Load Haul Dump Machine/ScoopTram

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiation
    Packaging Details: Suitable for Long Transportation
    Delivery Time: 2 Months
    Payment Terms: T/T, L/C, D/A, D/P, Western Union
    Contact Now
    Detailed Product Description
    Color:: Orange/Yellow/White Certification:: CE, ISO9001
    Application:: Tunnel/Underground Mining Bucket Capacity:: 3 Cubic Meter
    Engine:: DEUTZ BF6L914C Payload:: 6000 Kg
    Deadweight :: 17000 Kg


    DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3


    Competitive Advantage:


    1. CE, ISO9001 Certified
    2. Very competitive pricing
    3. Professinal Service Team
    4. Fast feedback about all questions from clients

    5. Design based on your specific requirements


    Applications:
    • Underground Mining
    • Hydropower Tunneling
    • Roadway/Railway Tunneling
    • Can be utilized as a multi-role equipment with various attachments (i.e. shotcrete robot arm)


    Operation Advantage:

    The RL-3 Load-Haul-Dump Machine is ideal for medium to large scale rock excavation operations. The RL-3 maintains the simple yet very robust design tenets of what a mining equipment should be - it has high proven reliability, and straight-forward mechanical components that are easy to maintain.



    Main Technical Configuration:


    Model:RL-3 Load Haum Dump Machine
    1 Rated Bucket Capacity(SAE, heaped)3.0 m3
    2 Payload6000 kg
    3 Deadweight17000 kg
    4 Bucket
    Maximum lift height4615 ± 50 mm
    Maximum dumping height1810 ± 50 mm
    Required dumping height clearance1621 ± 50 mm
    Dumping angle40 o ± 2 o
    5 Maximum tramming speed
    Laden forward/reverse, on a level roadway

    1st Gear4.7 km/h
    2nd Gear9.5 km/h
    3rd Gear16.4 km/h
    6 Gradeability14% - Minimum speed of 3.5 km/h (based on good road conditions)
    34% - Minimum speed of 2.5 km/h
    (based on good road conditions)
    7 Engine
    ModelDEUTZ BF6L914C
    DesignTurbocharged, charge air cooler, air-
    cooled diesel engine
    Max. power144 kW/2500 rpm
    Max. torque700 Nm/1600 rpm
    8 Torque converterDANA R32420
    9 Axles
    Front Axle
    ModelDANA 16D2149LCB
    DesignRigid planetary axles with no-spin
    differential gear
    Rear Axle
    ModelDANA 16D2149LCB
    DesignRigid planetary axles with no-spin
    differential gear
    Swing angle± 10o
    10 Minimum Turning Radius3600mm Inside,
    6400mm Outside
    11 Maximum Steering Angle40o
    12 Minimum Ground Clearance≥280 mm
    13 Size
    Length(Bucket in haul position)8868 mm
    Width2112 mm
    Height of the Cab2275 mm




    Packaging & Shipping
    By Truck:



    DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3

    By Container:
    DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3
