Home ProductsThreaded Drill Rod

R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System

R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System

    • R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System
    • R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System
    • R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System
  • R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System

    Product Details:

    Place of Origin: Shangdong,China
    Brand Name: MIROC
    Certification: API
    Model Number: 4148300417-4148300578

    Payment & Shipping Terms:

    Minimum Order Quantity: 50 Pieces
    Price: negotiation
    Packaging Details: Wooden Plate
    Delivery Time: 10-25days
    Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability: 20000pcs per month
    Contact Now
    Detailed Product Description
    Material: Tungsten Carbide Use: Tunneling, Mining,Quarrying,Construction
    Processing Type: CNC Milling And Proprietary Heat Treatment Process Diameter: 25-35mm
    Length: 610-6400mm Thread: R25/R28/R32
    Type: Thread Drill Rods

    R25 R28 R32 Drifter Drill Rod With Hex 25/28/35mm Diameter For Rock and Mining Drill



    Describtion



    Produce Hexagonal and round cross sections.

    Hexagonal cross sections rods are more rigid, heavier and transfer energy more efficiently, while increasing flushing.

    Round rods are generally lighter than hexagonal rods and are normally used in extension drilling applications.

    With the longer steel tending to be larger in diameter, conventional extension steel is characterized by a duplicate thread on each end of the steel.,



    For Extension Rod and M/F steel process, the below two different types of heat treatment are used to strengthen high speed and powerful percussive drill string components to maximize their performance and reliability. Longer steel larger in diameter, conventional extension steel, Hexagonal and round cross sections are available.
    1.Carburization is a process used to harden the entire rod surface both internally and externally to strengthen and extend the life of the rod.
    2. High Frequency Induction is a process where only the thread ends of the rod are hardened to lengthen thread life.



    Widely used in drifting, tunneling, benching, and long hole drilling

    Material: Tungsten carbide and high strength alloy steel

    Processing: CNC milling and proprietary heat treatment process



    Specification



    Thread Type

    R22, R25, R28, R32, R38, T38, T45, T51, ST58, ST68...

    Body Type

    Round / Hexagonal

    Diameter

    Hex25, Hex28, RD32, RD38, RD45, RD51…

    Length

    250mm-6400mm (L)

    Material

    High Quality Carbon Steel (20CrNi3Mo equivalent to SANDBAR 64)

    Package

    In wooden case or in bundles











    Product Name

    Size

    Specification

    Length

    R25 Rod

    Hex25

    R25-Hex25-R25

    610mm, 915mm, 1220mm,

    1525mm,1830mm,2435mm,

    3050mm, 3660mm

    R32-Hex25-R25

    1830mm,2130mm,2475mm,

    2795mm,3090mm,3700mm

    Hex28

    R32-Hex28-R25

    3090mm, 3700mm

    R38-Hex28-R25

    R28 Rod

    Hex28

    R32-Hex28-R28

    2475mm,2590mm,3090mm,

    3700mm,4005mm,4305mm

    R38-Hex28-R28

    3090mm, 3700mm,4305mm

    R32 Rod

    Hex32

    R32-Hex32-R32

    2475mm,3090mm,3700mm,

    4305mm

    R38-Hex32-R32

    2475mm,3090mm,3700mm,

    4005mm,4305mm, 4610mm,

    4915mm

    T38-Hex32-R32

    4305mm

    Hex35

    R38-Hex35-R32

    3090mm,3700mm,4305mm,

    4915mm,5525mm

    T38-Hex35-R32

    3090mm,3700mm,4305mm,

    4915mm,5525mm,6135mm

    T38-Hex35-R32 MF-rod

    3090mm,3700mm,4305mm,

    4915mm,5525mm,6140mm

    RD39

    R38-RD39-R32

    4305mm

    T38-RD39-R32

    4305mm,4915mm,5525mm,

    6135mm



    R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System

    R25 R28 R32 Hexagon MF Extension Rods for Drifting and Tunneling With 610-6400mm Length , Thread System

    Extension Rod(MM Rod)

    R32-Round32-R32 length 3 4 6 8 10 12 ft
    T38 (R38) Round39-T38 (38), length 4' 6' 10' 12'ft
    T45 -Round46-T45, length 10' 12' 14' 20' ft
    T51 -Round52-T51, length 12' 14' 20' ft


    Male/Female (M/F) rod, Speed rod
    M/F drill steel is an alternative to couplings sleeves to include the female part of the threaded connection as an integral part of the drill steel. M/F drill steel provides more rigid connections and is easier to uncouple and handle. The service life also tends to be better than with separate couplings.

    Advantages of drilling with M/F rods:

    A: Easy handling

    B: quicker uncoupling

    C: tighter connections

    D: the potential to drill straighter holes

    E: longer service life.



    MF-rod R32-Round32-R32, length 3 4 5 6 10 12 14 ft
    MF Rod T38-Round39-T38, length 4 5 6 10 12 14 ft
    MF Rod T45-Round46-T45, length 5 6 10 12 14 20 ft
    MF Rod T51-Round52-T51, length 6 12 14 20 ft
    MF Rod ST58-Round60-ST58, length 12 14 20 ft
