| Place of Origin: | China |
| Brand Name: | MIROC |
| Model Number: | 4148300452-4148300457 |
| Minimum Order Quantity: | 50 |
|---|---|
| Price: | negotiation |
| Packaging Details: | Carton Box or Wooden Box |
| Delivery Time: | 25 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 20000 pieces per month |
| Material: | Tungsten Carbide | Color: | Green,red.yellow Etc |
|---|---|---|---|
| Type: | R25 R28 R32 | Processing: | CNC Milling |
| High Light: | reamer drill bit,tungsten drill bits |
||
Description
Reaming rock bit applicable to reaming for first-grade and second-grade larger-diameter hole. It can reduce the sectional area between bit blade and rock hole, also solve the problem of large diameter's low drilling speed in the hard formation with good directive.
reaming bits for quarry are designed to enlarge pilot holes for development rounds,
long hole blasting of drop raises and constructing service holes.
With Pilot adaptors, the drilling direction can be ensured and accurate.
Our factory Reamer is ideal for use with rotary steerable drilling systems, providing a wellbore quality not achievable with other reaming tools. Superior wellbore quality, coupled with a proven history of performance, makes the Reamer the choice for underreaming operations.
Competitive Advantage
• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
specification
| R25 Reaming Bit 6 ° | ||||||
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 64 | 2x10 | 8x9 | - | - | 0.8 |
| 2 | 64 | 4x8 | 8x9 | - | - | 0.8 |
| 3 | 76 | 2x11 | 8x11 | - | - | 1.2 |
| 4 | 76 | 4x10 | 8x10 | - | - | 1.2 |
| 5 | 89 | 4x11 | 8x11 | - | - | 1.7 |
| 6 | 89 | 4x10 | 8x10 | - | - | 1.7 |
| R25 Pilot Adapter 6 ° | ||||||
| 1 | 26 | 12x8 | - | - | 1.3 | |
| R28 Reaming Bit 6 ° | ||||||
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 64 | 2×10 | 8×9 | - | - | 0.8 |
| 2 | 64 | 4×8 | 8×9 | - | - | 0.8 |
| 3 | 76 | 2×11 | 8×11 | - | - | 1.2 |
| 4 | 76 | 4×10 | 8×10 | - | - | 1.2 |
| 5 | 89 | 4×11 | 8×11 | - | - | 1.7 |
| 6 | 89 | 4×10 | 8×10 | - | - | 1.7 |
| R28 Pilot Adapter 6 ° | ||||||
| 1 | 26 | 12x8 | - | - | 1.3 | |
<
| R32 Reaming Bit 6 °/ 12° | ||||||
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 64 | 2×10 | 8×9 | - | - | 0.8 |
| 2 | 64 | 4×8 | 8×9 | - | - | 0.8 |
| 3 | 76 | 2×11 | 8×11 | - | - | 1.2 |
| 4 | 76 | 4×10 | 8×10 | - | - | 1.2 |
| 5 | 89 | 4×11 | 8×11 | - | - | 1.7 |
| 6 | 89 | 4×10 | 8×10 | - | - | 1.7 |
| 7 | 102 | 4×12 | 8x12 | - | - | 2.1 |
| 8 | 127 | 4×12 | 8x12 | - | - | 4 |
| 9 | 127 | 4×13 | 8x13 | - | - | 4 |
| R32 Pilot Adapter 6 ° / 12° | ||||||
| 1 | 26 | 12x8 | - | - | 1.3 | |
| 2 | 40 | 15x10 | - | - | 2.2 | |
Packaging:Carton or Wooden Box
