High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling

High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling

  • High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling
  • High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling
High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling
Product Details:
Place of Origin: Shangdong,China
Brand Name: MIROC
Certification: ISO9001:2000
Model Number: RC Bits
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pieces
Price: negotiation
Packaging Details: Carton Box or Wooden Box
Delivery Time: 10-22days after receiving payment and order confirmation
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 30000pcs per month
Contact Now
Detailed Product Description
Type: RC Bits Material: Tungsten Carbide
Series: RC-E545 Processing Type: Forging
Bit Dia.: 143MM Application: Used For Deep Exploration Drilling And Ore Grade Control
High Light:

carbide tipped drill bits

,

dth button bits



High grade tungsten carbide inserts DTH Tools RC-E545 Bits and Hammers

For Mining Well Drilling



In DTH drilling, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH drilling a nearly constant penetration rate regardless of hole length.



DTH bits are paired with their corresponding hammers (by drilling hole diameter and spline configuration). Customers can customize their DTH bits in various ways, such as changing the tungsten carbide insert profile (spherical, ballistic, etc.), face profile (flat face, concave, convex, etc.), and flushing holes.



Characteristics of Reverse Circulation Bits:

1.Based on previous experience of ordinary hammers, combined with the features of reverse circulation hammer, optimized internal structure and ideal energy transfer, thus ensuring the series of hammers drilling with fast, smooth and continuous sampling.



2. The internal structure is very simple with components of high rigidity, thus ensuring long life and easy maintenance of the hammer.



3.The collection tube adopts an integrative design and can be replaced without disassembling the hammer. With carburizing treatment, it has good abrasive resistance.



4.Equipped with bits designed with patent. Simply by replacing the drill bit, the same hammer can drill holes of different sizes ensuring that the sample is not contaminated.



5. In difficult conditions such as loose soil, hard rock and plenty of water exists, sampling can be done well.



High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling 0High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling 1High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling 2High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling 3High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling 4

Specification of Reverse Circulation Bits

Drill Bit Bit Dia.              (mm) NO.Air Holes Gauge Buttons Front Buttons Weight(Kg)
MIC 133 2 8×φ16 8×φ16 17.5
140 2 8×φ16 8×φ14 18
146 2 8×φ18 8×φ14 20
PR5 133 2 8×φ16 8×φ14 12.5
140 2 8×φ16 8×φ14 13
146 2 8×φ18 8×φ14 13.5
PR4 115 2 8×φ16 8×φ13 14.4
127 2 8×φ16 8×φ14 15
133 2 8×φ16 8×φ14 15.5





Applications
• Underground mining
• Down the hole rock drilling



Competitive Advantage
• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment



Delivery time and Package

Delivery time: around 15-20days

Package: Carton or Wooden Box/Based on customers requirements

High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling 5


Our Services



KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:

  • Hazardous environment
  • Acts, regulations, and other government guidelines that has to be followed
  • Significant differences in the way people work, mostly due to physical constraints
  • Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.

Company Information



KSQ Technologies (Beijing) Co. Ltd. is a diversified enterprise based in Beijing, China, offering a portfolio of products that help contribute to a better bottom line and increase workplace safety for the construction and mining industries.

KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations. Our operations are based on the unique expertise of our people and knowledge with customer processes.

Our portfolio includes:

Consumables used in the mining and construction industries
Equipment used in the mining and construction industries
Spare parts used for the equipment we sell for the mining and construction industries
Green technologies, such as products that reduce electric consumption or use alternate sources of energy (solar, wind, etc.)



High Grade Tungsten Carbide Drill Bits Dth Tools Rc-e545 For Mining Well Drilling 6
