Mining Machine DTH Drilling Tools API 2 3/8 Water Well Drilling Dth Pipe

Mining Machine DTH Drilling Tools API 2 3/8 Water Well Drilling Dth Pipe

  • Mining Machine DTH Drilling Tools API 2 3/8 Water Well Drilling Dth Pipe
  • Mining Machine DTH Drilling Tools API 2 3/8 Water Well Drilling Dth Pipe
Mining Machine DTH Drilling Tools API 2 3/8 Water Well Drilling Dth Pipe
Product Details:
Place of Origin: Shangdong,China
Brand Name: MIROC
Certification: ISO9001
Model Number: Drilling Dth Pipe
Payment & Shipping Terms:
Minimum Order Quantity: 5 Pieces
Price: negotiation
Packaging Details: Carton Box or Wooden Box
Delivery Time: 10-22days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 30000pcs per month
Contact Now
Detailed Product Description
Type: Drilling Dth Pipe Length: 1000mm-10000mm
Diameter: 60MM 76MM 89MM 102mm 108mm 114mm 152mm Application: Water Well,blasting Holes,drilling For Ground Thermal
Connection Thread: T42*10*2 ,2 3/8” API REG/IF,2 7/8” API IF,3 1/2” API REG Produce Type: Heat-treated And Friction-welded
High Light:

rock drill tools

,

downhole drilling tools

Mining Machine DTH Tools API 2 3/8 Water Well Drilling Dth Pipe



DTH drill rods (also called as drill tubes or drill pipes) are the mechanism to transmit impact force and rotation torque to DTH hammers and bits, as well as offer pass for the air flow.



In principle, the lighter the rod is, the better it is for the drilling operation. So a thinner one is always preferable than a thicker one if other parameters were the same. While in the mean time, the yield strength and the tensile strength must also be taken into accounts, which means relatively rod wall thickness would be needed to obtain enough strength. Of course, once the thickness is rigidly requested as thin as possible to minimize the drill string weight, there is also another method to get optimum drill tubes that using better grade steels.

Mining Machine DTH Drilling Tools API 2 3/8 Water Well Drilling Dth Pipe 0



Specification of Drilling Pipe

Diameter Length Connection Thread Wall Thickness
mm inch mm Foot mm inch
60 2.375 1,000~4,500 3 3/8 ~ 14 3/4 T42×10×2 5~8 13/64~5/16
76 3 1,000~4,500 3 3/8 ~ 14 3/4 2 3/8” API REG 5~8 13/64~5/16
89 3.5 1,000~7,620 3 3/8 ~ 25 2 3/8” API REG/IF 5~12 13/64~15/32
102 4 1,000~9140 3 3/8 ~ 30 2 3/8” API REG, 2 7/8” API IF, 3 1/2” API REG 6.5~20 1/4~25/32
108 4.25 1,000~9140 3 3/8 ~ 30 2 3/8” API REG, 2 7/8” API IF, 3 1/2” API REG 6.5~20 1/4~25/32
114 4.5 1,000~10,670 3 3/8 ~ 35 2 7/8” API IF, 3 1/2” API REG 6.5~20 1/4~25/32
127 5 1,000~10,670 3 3/8 ~ 35 3 1/2” API REG 8~20 5/16~25/32
133 5.25 1,000~10,670 3 3/8 ~ 35 3 1/2” API REG 8~20 5/16~25/32
140 5.5 1,000~10,670 3 3/8 ~ 35 3 1/2” API REG 10~22 25/64~7/8
146 5.75 1,000~10,670 3 3/8 ~ 35 3 1/2” API REG 10~22 25/64~7/8
152 6 1,000~10,670 3 3/8 ~ 35 4 1/2” API REG 10~22 25/64~7/8



Sub Adapter

Type Diameter Length Connection Thread
mm inch mm inch API REG/IF
Pin to Box 59~146 2 3/8 ~ 5 3/4 120~235 4 23/32 ~ 9 1/4 2 3/8”, 2 7/8”, 3 1/2”, 4 1/2”
Pin to Pin 90~115 3 1/2 ~ 4 1/2 70~97 2 3/4 ~ 3 5/8 2 3/8” , 2 7/8”, 3 1/2”
Box to Box 77~205 3 ~ 8 1/8 200~270 7 7/8 ~ 10 5/8 2 3/8”, 2 7/8”, 3 1/2”, 4 1/2”, 6 5/8”
