T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits

T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits

T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits
T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits
T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits
Product Details:
Place of Origin: China
Brand Name: MIROC (KSQ)
Certification: ISO
Model Number: Retract Button Bit
Payment & Shipping Terms:
Minimum Order Quantity: Negotiated one
Price: Negotiable
Packaging Details: Carton or Wooden Box
Delivery Time: 10 - 20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 pcs per Month
Contact Now
Detailed Product Description
Thread: T38 Type Of Bit: Retrac Button Bit
Type Of Buttons: Spherical And Ballistic Material: Tungsten Carbide, High Strength Alloy Steel
Application: Mining Operations, Bench Drilling, Drifting And Tunneling, Quarrying, Construction Color: Black, Green Or Based On Requests
Diameter, Mm: 64, 70,76, 89
Highlight:

stone drilling bits

,

spherical drill bit

T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits



Spherical and Ballistic Buttons

Drill Bit Diameter, mm No x Buttons Diameter Flushing Hole Weight, kg
Front Gauge Angle Front Side
Retrac Button Bit Spherical / Ballistic
64 4x10 8x10 30 2 - 2.2
64 3x10,1x10 6x11 35 3 - 2.2
70 4x11 8x11 40 2 - 2.4
70 3x10,1x10 6x13 35 3 - 2.4
70 4x10,1x10 8x11 35 4 - 2.4
76 4x11 8x11 40 2 - 3.3
76 4x11,1x11 8x11 35 4 - 3.3
76 4x11,1x11 8x12 35 4 - 3.3
89 4x13 8x13 40 2 - 4.8
89 5x13 8x13 35 2 - 4.8
89 6x11 8x12 35 2 - 4.8
89 4x11,1x11 8x13 35 4 - 4.8
89 4x13,1x13 8x13 35 4 - 4.8

T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits 0

Description:

Thread Button bit is well known for its high wear resistance on medium-hard to hard abrasive rock formations . Featuring spherical  and ballistic tungsten carbide inserts that is known to have strong configuration against carbide fracture.



Application:
1. Underground Mining
2. Widely used in drifting and tunneling

3. Used in small hole drilling.

4. Bench Drilling

T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits 1



Features:
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance.



Package: Carton or Wooden Box; also we can follow customers' requirements.

Delivery time is around 15-25 days.

T38 Diameter 64 - 89mm With CNC Milling / Heat Treatment Process Retrac Drill Button Bits 2

P.S. We can design and manufacture products according to customers’ requirements.
