High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying

High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying

High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying
High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying
High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying
Product Details:
Place of Origin: China
Brand Name: MIROC
Certification: ISO
Model Number: T45 Button bit
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiated price
Packaging Details: dth drill bits first be packed in polybag,then be packed in plastic box or wooden box
Delivery Time: 5-15 working day
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram,Paypal
Supply Ability: 100 000pcs/month
Contact Now
Detailed Product Description
Product: T45 Button Bit Diameter: 70 76 89 102mm
Length: 190mm Type: Threaded Drilling Tools
Angle: 35° Button Bit Shape: Spherical And Ballistic
High Light:

mining drill bits

,

spherical drill bit

High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying



Product Name: Thread Button bits
Description: Thread Button bit s
Button bit Made with high quality of best quality alloy steel bar and tungsten carbide, through heat treatment like Atlas.
Material: Alloy steel bar and tungsten carbide bit
MOQ: No MOQ required for testing and trial order
Body Type  Retract type
Thread type T45
Diameter 70mm,76mm,89mm,102mm
Button bit shape Spherical and Ballistic
Face shape Flat shape and Drop- C enter shape



Specification sheet

Product Name Bit Diameter Carbide Button Angle Flushing Hole Weight (kg)
(mm) (inch)

Front

(No. x mm)

Gauge

(No. x mm)

Front Side
T45 Retrac Bit 70 2 3/4 3x11, 1x9 6x11 35° 3 - 2.5
70 2 3/4 4x10, 1x10 8x11 35° 4 - 2.5
76 3 4x11 8x11 40° 2 - 3.2
76 3 4x11 8x12 35° 2 1 3.2
76 3 3x11, 1x11 6x13 35° 3 1 3.2
76 3 4x11, 1x11 8x11 35° 4 - 3.2
76 3 4x11, 1x11 8x12 35° 4 - 3.2
89 3 1/2 4x13 8x13 40° 2 - 5.4
89 3 1/2 6x11 8x12 35° 2 - 5.4
89 3 1/2 3x11, 2x11 8x13 35° 3 1 5.4
89 3 1/2 4x11, 1x11 8x12 35° 4 - 5.4
89 3 1/2 4x13, 1x13 8x13 35° 4 - 5.4



Our main products are as below:

Construction & Mining & Rock Drill Tools:

A. DTH Hammer and Bit (2''-24''), Overburden Drilling System; RC System

B. Top Hammer (drill hole dia.: 33 ~ 152mm):

1) Thread Tools (Button Bits, Rod, Coupling, Shank Adaptor): (R25/28/32/38, T38/45/51, ST58,GT60)

2) High Rang Soundless Cracking Agent (dia. 40 ~ 50mm)



Package and shipping

1. Packing details : Carton box and Wooden box .



2. Handling time for an order
Based on order quantity, normally it takes 15-30 days for production.
Only 2 or 3 days if we have stock on your request size.


3. Shipping way
Sample order: We suggest Express like DHL/UPS/TNT/FEDEX/EMS or by air.
Bulk order: We suggestby sea shipment or by airway cargo.



High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying 0High Wear Resistance 70~102mm T45 Button Drill Bit For Mining And Quarrying 1

Company instruction

We offer a full range of rock drilling tools products. Such products are provided as top hammer percussive drilling tools, down the hole (DTH)drilling tools, overburden casing advance system, rotary tricone drilling tools, carbide grinding equipment etc, in past of 15 years, KSQ products has widely in varies industries, mining, quarrying, water well digging, blasting hole, coal mine, salt mine, and underground mine all over the world.
 KSQ tools are perfectly compatible with the world famous brand such as Atlas Copco, Ingersoll-Rand with durability and longer drilling life. After years efforts and development done, Thanks to reliable quality, competitive prices, professional and valuable services, we now have grown to be a leading supplier of rock drilling tools in China. Our products had been sold into 55 countries, such as Norway ,France, Sweden, USA, Canada, Italy and Spain, meanwhile, we are gaining recognition and praise from a growing number of clients.
