| Place of Origin: | Shandong, China |
| Brand Name: | MIROC |
| Certification: | ISO, API |
| Model Number: | API Reg Thread DTH Drill Pipe |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | Standrad export packaging or customised |
| Delivery Time: | 15-20 days |
| Supply Ability: | 20000pcs per month |
| Material: | Carbon Steel | Type: | DTH Drill Pipe |
|---|---|---|---|
| Processing: | Forging, Friction Welding | Application: | Water Well Drilling, Mining, Rock Drilling, Quarry |
| Diameter: | 76/89/102/114/127mm | Length: | 1-12m |
| Advantage: | Durability, Accuracy, Manageability | Other Name: | Mining Drill Pipe, Water Well Drill Pipe |
| High Light: | 76mm dth drill pipe,dth drill pipe 76mm,12m Length dth drill pipe |
||
Description
The high pressure air is delivered to DTH hammer by DTH drill pipe, simultaneously it transfer the rotation and press force to the DTH hammer.
DTH drill pipes are widely used in mining,water well drilling,geothermal,oil and all kinds of DTH rock drilling,with high quality low carbon steel to ensure good resistance to strengthen and tensile,friction welded to ensure the adapter and pipe connect tightly as a whole set the cyclic extrusion-compression ensure reliable pipe.
Specification
| Diameter (mm) |
Thread | Thickness (mm) |
Length (mm) |
Wrench Flat (mm) |
Weight (kg) |
Part Number |
| 76 | 2 3/8 API Reg | 5.5 | 1000 | 57 | 17 | 4148301544 |
| 76 | 2 3/8 API Reg | 5.5 | 1500 | 57 | 22 | 4148301545 |
| 76 | 2 3/8 API Reg | 5.5 | 2000 | 57 | 26 | 4148301546 |
| 76 | 2 3/8 API Reg | 5.5 | 3000 | 57 | 35 | 4148301547 |
| 76 | 2 3/8 API Reg | 5.5 | 1000 | 65 | 17 | 4148301548 |
| 76 | 2 3/8 API Reg | 5.5 | 1500 | 65 | 22 | 4148301549 |
| 76 | 2 3/8 API Reg | 5.5 | 2000 | 65 | 26 | 4148301550 |
| 76 | 2 3/8 API Reg | 5.5 | 3000 | 65 | 35 | 4148301551 |
| 76 | 2 3/8 API Reg | 6.5 | 3000 | 65 | 46 | 4148301552 |
| 76 | 2 3/8 API Reg | 6.5 | 4500 | 65 | 56 | 4148301553 |
| 76 | 2 3/8 API Reg | 6.5 | 6000 | 65 | 73 | 4148301554 |
| 89 | 2 3/8 API Reg | 5.5 | 1000 | 65 | 20 | 4148301555 |
| 89 | 2 3/8 API Reg | 5.5 | 1500 | 65 | 25 | 4148301556 |
| 89 | 2 3/8 API Reg | 5.5 | 2000 | 65 | 30 | 4148301557 |
| 89 | 2 3/8 API Reg | 5.5 | 3000 | 65 | 40 | 4148301558 |
| 89 | 2 3/8 API Reg | 6.5 | 1000 | 65 | 21 | 4148301559 |
| 89 | 2 3/8 API Reg | 6.5 | 1500 | 65 | 26 | 4148301560 |
| 89 | 2 3/8 API Reg | 6.5 | 2000 | 65 | 32 | 4148301561 |
| 89 | 2 3/8 API Reg | 6.5 | 3000 | 65 | 45 | 4148301562 |
| 89 | 2 3/8 API Reg | 6.5 | 4500 | 65 | 65 | 4148301563 |
| 89 | 2 3/8 API Reg | 6.5 | 6000 | 65 | 84 | 4148301564 |
