| Place of Origin: | CHINA |
| Brand Name: | MIROC |
| Certification: | ISO |
| Model Number: | CIR90 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard export packing |
| Delivery Time: | 15-20 days |
| Supply Ability: | 5000 pcs per month |
| Material: | Carbon Steel | Application: | Water Well Drilling |
|---|---|---|---|
| Buttons: | Spherical, Ballistic | Face Type: | Flat, Concave, Covex |
| Product Name: | Low Pressure DTH Drill Bit | Advantage: | High Wear Resistant Cemented Carbide |
| Processig Type: | Forging | Packing: | Wooden Cace Or As Requrements |
| High Light: | 90mm rock drill bit,law air pressure rock drill bit,dth hammer bit 90mm |
||
Description
DTH bit is the tool cutting rocks, and subject to severe stress from the striking piston as well as from the abrasive cuttings passing the bit at high velocity. When selecting the right bit for optimum performance you have to balance penetration against bit life. On occasion you can successfully sacrifice bit life for penetration, remember the rule of thumb that states that a 10% increase in penetration covers at least a 20% loss in bit life.
Our products are compatible with most of the products manufactured by , Atlas Copco, etc. DTH drill bits are widely used in mining, tunneling, quarrying, construction and civil engineering project.
Specification
| Drill Bit | Bit Dia. | Spline Key Number | Buttons (mm) | NO. Air Holes | Weight | ||
| mm | inch | Front | Gauge | (kg) | |||
| CIR90 Ballistic Convex Face |
90 | 3 5/9 | 6 | 2x13, 2x12 | 6x14 | 2 | 3.5 |
| 93 | 3 2/3 | 6 | 2x13, 2x12 | 6x14 | 2 | 3.6 | |
| 95 | 3 3/4 | 6 | 2x14, 2x12 | 6x14 | 2 | 3.7 | |
| CIR90 Spherical Flat Face |
90 | 3 5/9 | 6 | 4x12 | 6x14 | 3 | 3.5 |
| 93 | 3 2/3 | 6 | 4x12 | 6x14 | 3 | 3.6 | |
| 95 | 3 3/4 | 6 | 4x12 | 6x14 | 3 | 3.7 | |
