12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling

12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling

  • 12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling
  • 12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling
  • 12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling
  • 12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling
12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling
Product Details:
Place of Origin: Shandong, China
Brand Name: MIROC
Certification: ISO
Model Number: Taper Button Bit
Payment & Shipping Terms:
Minimum Order Quantity: 20 pcs
Price: Negotiation
Packaging Details: Carton, wooden boxes or customized
Delivery Time: 15-20 days
Supply Ability: 20000 pcs per month
Contact Now
Detailed Product Description
Material: Tungsten Carbide Bit Dia.: 32mm To 45mm
Name: Tapered Button Bit Skirt: Short Skirt, Long Skirt
Flushing Holes: 2 Or 3 Taper Degree: 7, 11, 12 Degree
Button Shape: Ballistic, Spherical, Conical
High Light:

12 degrees tapered button bit

,

tapered button bit 38mm

,

short skirt tapered button bit

12 Degress 38mm Short Skirt Tapered Button Bit For Small Hole Drilling



Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered cross type bits if the goal is to minimize hole deviation in small hole range drilling. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning. Used in drifting and tunneling.



Features:



1. Tapered button bits connect with tapered drill rod for drilling holes

2. Stale and mature welding technology ensure good quality of bits

3. Accurate dimension of taper degree perfectly matches the rods

4. Work reliable and very cost-effective



Applications:



• Underground mining

• Dimensional Stone Industry
• Tunneling,quarrying





Specifications



12° Tapered Button Bit Bit Dia. Buttons and Size (mm) Flushing Hole Weight Product Code
mm inch Front Gauge Front Side kg

Button Bit, Short Skirt
BS4XX
28 1 1/9 1x7 3x7 1 1 0.2 BS428-12D-22
29 1 1/7 1x7 3x7 1 1 0.21 BS429-12D-22
30 1 1/6 1x7 3x7 1 1 0.22 BS430-12D-22

Button Bit, Short Skirt
BS5XX
28 1 1/9 2x7 3x7 1 1 0.2 BS528-12D-22
30 1 1/6 2x7 3x7 1 1 0.22 BS530-12D-22

Button Bit, Short Skirt
BS6XX
30 1 1/6 2x7 4x7 1 1 0.22 BS630-12D-22
35 1 3/8 2x7 4x7 1 1 0.33 BS635-12D-22
38 1 1/2 2x9 4x9 1 1 0.4 BS638-12D-22

Button Bit, Short Skirt
BS7XX
32 1 1/4 2x7 5x7 2 1 0.24 BS732-12D-22
33 1 2/7 2x7 5x7 1 1 0.25 BS733-12D-22
34 1 1/3 2x7 5x8 1 1 0.29 BS734-12D-22
35 1 3/8 2x7 5x8 2 1 0.33 BS735-12D-22-1
35 1 3/8 2x7 5x9 1 1 0.33 BS735-12D-22-2
36 1 3/7 2x7 5x9 1 1 0.37 BS736-12D-22
37 1 4/9 2x7 5x9 1 1 0.38 BS737-12D-22
38 1 1/2 2x7 5x9 1 1 0.4 BS738-12D-22

Button Bit, Long Skirt
BL7XX
32 1 1/4 2x7 5x7 1 1 0.3 BL732-12D-22
33 1 2/7 2x7 5x7 1 1 0.31 BL733-12D-22
35 1 3/8 2x7 5x9 1 1 0.38 BL735-12D-22
36 1 3/7 2x7 5x9 1 1 0.39 BL736-12D-22
38 1 1/2 2x7 5x9 1 1 0.41 BL738-12D-22
41 1 5/8 2x7 5x9 1 1 0.42 BL741-12D-22

Button Bit, Long Skirt
BL8XX
33 1 2/7 2x7 6x7 2 1 0.31 BL833-12D-22
35 1 3/8 2x7 6x7 2 1 0.35 BL835-12D-22



12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling 0





Package

12 Degrees 38mm Short Skirt Tapered Button Bit For Small Hole Drilling 1
