Home ProductsThreaded Drill Rod

T38 3050mm Threaded Top Hammer Drilling Rod

T38 3050mm Threaded Top Hammer Drilling Rod

  • T38 3050mm Threaded Top Hammer Drilling Rod
  • T38 3050mm Threaded Top Hammer Drilling Rod
  • T38 3050mm Threaded Top Hammer Drilling Rod
T38 3050mm Threaded Top Hammer Drilling Rod
Product Details:
Place of Origin: CHINA
Brand Name: MIROC
Certification: ISO
Model Number: T38 3050mm
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20000pcs per month
Contact Now
Detailed Product Description
Other Names: T Threaded Drill Rod, Drilling Rod, Rock Drill Rods, Material: Alloy Steel Bar
Rod Shape: Round (Plain) Machine Type: Drilling Tools
Processing Type: Forging Technology: Heat Treatment
Application: Hard Rock Drilling, Mining, Quarrying, Stoning, Construction Colour: Black
High Light:

t38 threaded drill rod

,

3050mm threaded drill rod

,

iso threaded drill rod

T38 3050mm Threaded Top Hammer Drilling Rod



Extension Steel Rods
With the longer steel tending to be larger in diameter. Conventional extension steel is characterized by a duplicate thread on each end of the steel. Hexagonal and round cross sections are available. Round cross sections are more prevalent.



Male/Female (M/F) steel
An alternative to couplings is to include the female part of the threaded connection as an integral part of the drill steel.Like most developments, it has its advantages and disadvantages. Male/Female drill steel pro- vides more rigid connections and is easier to uncouple and handle. The service life also tends to be better than with separate couplings. This is fortunate because the coupling end cannot be re-placed.The advantages of drilling with M/F steel include: easy handling, quicker uncoupling, tighter con-nections and the potential to drill straighter holes.



Specification of thread drill rod

Part Number Product Code and Brief Description

Length

(mm)

Length

(ft/inch)

Diameter

(mm)

Diameter

(inch)

Weight

(kg)

4148300796

GR32-T38-1830,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

1830 6 46 1 4/5 23.5
4148300797

GR32-T38-3050,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

3050 10 46 1 4/5 37.2
4148300798

GR32-T38-3660,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

3660 12 46 1 4/5 44.0
4148300799

GR32-T38-4270,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

4270 14 46 1 4/5 50.9
4148300800

GR32-T38-4880,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

4880 16 46 1 4/5 57.7
4148300801

GR32-T38-5530,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

5530 18 1/7 46 1 4/5 65.0
4148300802

GR32-T38-6095,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

6095 20 46 1 4/5

71.3



T38 3050mm Threaded Top Hammer Drilling Rod 0T38 3050mm Threaded Top Hammer Drilling Rod 1T38 3050mm Threaded Top Hammer Drilling Rod 2T38 3050mm Threaded Top Hammer Drilling Rod 3T38 3050mm Threaded Top Hammer Drilling Rod 4T38 3050mm Threaded Top Hammer Drilling Rod 5T38 3050mm Threaded Top Hammer Drilling Rod 6
