Product Details:
Place of Origin: CHINA
Brand Name: MIROC
Certification: ISO
Model Number: 11 Degree 38mm
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Carton Box or Wooden Box
Delivery Time: 5-15 Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20000 pieces per month
Contact Now
Detailed Product Description
Product Name: China Supplier Tapered Bit Color: Customized
Formation: Soft , Medium , Hard , Very Hard Skirt Type: Short/long Skirt Tapered Bit
Usage: Gold Mining , Coal Mining , Blasting Advantage: Lower Unit Drilling Cost
High Light:

11 degree tapered button bit

,

38mm button bit for rock drilling

,

blasting button bit for rock drilling

11 Degree 38mm Tapered Rock Drill Button Bit



Product features

Top quality taper chisel drill bits, taper cross bit, taper button bitclose to world famous brand drill bit

KSQ can manufacture the following types according to clients need taper: 4, 6, 7, 11, 12 degree taper. The diameter for taper: 15, 19, 22, 25,, and diameter 26 28, 30, 32, 34, 36, 38 to 42(mm)

Furthermore, these products are manufactured in accordance with IS09001 stipulations.
We can design and manufacture drill bits according to customers' requirement of the bit diameter, number of air holes, carbide button shape and the face shape.

Our clients
Are all over the world, like Germany, Spain, Italy, Russia, Japan, India, Australia, Mexico, Colombia, Brazil,
Chile, South Africa...etc. We have very good reputation worldwide!

Product Technical Reference

Small HoleDrilling Tools Taper Degree The NumberOf Button Bit Dia.(mm) Skirt Weight(kg)
Tapered   4 32-42 Short Skirt 0.24-0.43
  6 34 Short Skirt 0.29
7 32-42 Short Skirt 0.26-0.43
  7 32-41 Long Skirt 0.30-0.42
  4 32-40 Short Skirt 0.24-0.40
11° 5 38-40 Short Skirt 0.39-0.40
  6 33-36 Short Skirt 0.25-0.36
  7 32-41 Short Skirt 0.24-0.41
  7 32-41 Long Skirt 0.30-0.42
  8 33-35 Long Skirt 0.31-0.35
12° 4 28-30 Short Skirt 0.20-0.22
5 28-30 Short Skirt 0.20-0.22
6 30-38 Short Skirt 0.22-0.40
7 32-38 Short Skirt 0.24-0.40
7 32-41 Long Skirt 0.30-0.42
8 33-35 Long Skirt 0.31-0.35

11 Degree 38mm Tapered Button Bit For Rock Drilling 0

Before Official Order, please confirm below informations:
(1) Degree Type
(2) Diameter
(3) Length of skirt.
(4) Socket

A. Tapered chisel bits
The tapered chisel bit is widely used in drilling holes with depth less than
5 meters and diameter ranged in 20-45 mm by light-duty rock drill, like Y6

B. Tapered cross bits
The taper cross bits can be used under any rock drilling condition because of it's comprehensive adaptability. Compared with taper chisel bits, taper cross bits have a better drilling performance because carbide tips on cross bits doubled, which means carbides shape are cross type on drill bits. Taper cross bit is mainly used for hard or very hard rock formation.

C. Tapered button bits
Comparing with tapered chisel bits and tapered cross bits, button bits has higher technology, much longer primary drilling time and higher drilling efficiency, so that the button bit is popular among the users.
According to the tungsten carbide insert, tapered button bits can be divided into the types of hemispherical button, conical button and parabolic button, etc.
Button bits with hemispherical button is for high bearing capacity and abrasive resistance while conical button and parabolic button are for high drilling speed and low abrasive resistance.

11 Degree 38mm Tapered Button Bit For Rock Drilling 111 Degree 38mm Tapered Button Bit For Rock Drilling 211 Degree 38mm Tapered Button Bit For Rock Drilling 311 Degree 38mm Tapered Button Bit For Rock Drilling 411 Degree 38mm Tapered Button Bit For Rock Drilling 511 Degree 38mm Tapered Button Bit For Rock Drilling 611 Degree 38mm Tapered Button Bit For Rock Drilling 7
