R38 170 - 190mm Underground Mining Drill Threaded Coupling

R38 170 - 190mm Underground Mining Drill Threaded Coupling

R38 170 - 190mm Underground Mining Drill Threaded Coupling
R38 170 - 190mm Underground Mining Drill Threaded Coupling
R38 170 - 190mm Underground Mining Drill Threaded Coupling
Product Details:
Place of Origin: China
Brand Name: MIROC
Certification: ISO
Model Number: R38 170 - 190mm
Payment & Shipping Terms:
Minimum Order Quantity: 50
Price: negotiation
Packaging Details: Carton Box or Wooden Box
Delivery Time: 25 days
Payment Terms: T/T or L/C
Supply Ability: 20000 pieces per month
Contact Now
Detailed Product Description
Color: Black Or Customized Use: Quarry,construction,blasting,open Pit And Underground Mining,etc
Shape: Circular Type: Coupling Sleeves
Advantage: High Performance Quality: OEM Standard
High Light:

crossover coupling

,

threaded coupling

R38 170 - 190mm Underground Mining Drill Threaded Coupling



Description

Coupling sleeves are available with both half-bridge and full-bridge types, as well as adapter couplings.
Semi-bridge coupling, by far is the most popular, has a small non-threaded bridge in the centre. The drill rod cannot thread past the centre of the couplings, and the smaller diameter rods portions butt together in the centre bridge area of the coupling. Semi-bridge couplings are most suited to high torque machines. Most rope (R) and Trapezoidal (T) threaded couplings are semi-bridged.

Full bridge coupling has a great advantage that it positively eliminates the potential for the coupling to creep along the threaded joints. These couplings, are typically used in a Trapezoidal thread, in surface drilling application, have better uncoupling characteristics and tend to maintain tighter joints. Full-bridge couplings have less chance of jamming and are best suited to machines equipped with independent rotation.

Standard coupling using R38 thread system



Threaded coupling sleeve are made of high quality of alloy steels and CNC machining guarantee our reliable and consistent quality control of coupling sleeves.

Both semi-bridge and full-bridge coupling sleeves are manufactured by us in different sizes as below:Thread sizes: R22, R25, R28, R32, R35, R38, T38, T45, T51;
Two catagories: Standard coupling sleeves, adapter(crossover) coupling sleeves;

• R38 thread system
• Widely used in drifting and tunneling


Color: Green or Based on Customer requirements


Material: Tungsten carbide and high strength alloy steel


Processing: CNC milling and proprietary heat treatment process


Type: R38 Standard Coupling

Applications
• Underground Mining
• Tunneling


Competitive Advantage

High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance


Specification

Part Number

Product Code and Brief

Description

Length

(mm)

Length

(inch)

Diameter

(mm)

Diameter

(inch)

Thread

Weight

(kg)

4148300703

CS-R38-170, R38

Standard Coupling


170 6 2/3 55 2 1/6 R38 1.9
4148300704

CS-R38-190, R38

Standard Coupling

190 7 1/2 55 2 1/6 R38 2.1

R38 170 - 190mm Underground Mining Drill Threaded Coupling 0R38 170 - 190mm Underground Mining Drill Threaded Coupling 1
