| Place of Origin: | China |
| Brand Name: | MIROC |
| Model Number: | 4148300797-4148300802 |
| Minimum Order Quantity: | 50 |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden Plate |
| Delivery Time: | 25 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 20000 pieces per month |
| High Light: | Threaded Drill Rod,Drill Rod Threaded,drill extension rod |
||
|---|---|---|---|
Round Alloy Steel Rock Drill Rod T38 Guide Speed Rod Flushing Hole 17mm
Description
Drill rod using T38 thread system. Drilling precision can be further improved by using this as the first rod in a normal drill string. Furthermore, since this is a speed rod design it will produce straighter holes and at least 10% higher penetration rate in good rock conditions compared to rod and coupling sleeve combination system.
• R28 thread system
• Suitable for small hole range
Color: Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: T38 Guide Speed Rod T38-Round 46-T38 Flushing Hole 17 mm
Applications
• Underground Mining
• Tunneling
Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
specification
<
| Part Number | Product Code and Brief Description |
Length (mm) |
Length (ft/inch) |
Diameter (mm) |
Diameter (inch) |
Weight (kg) |
| 4148300796 |
GR32-T38-1830, T38 Guide Speed Rod, T38-Round 46-T38, Flushing Hole 17 mm |
1830 | 6 | 46 | 1 4/5 | 23.5 |
| 4148300797 |
GR32-T38-3050, T38 Guide Speed Rod, T38-Round 46-T38, Flushing Hole 17 mm |
3050 | 10 | 46 | 1 4/5 | 37.2 |
| 4148300798 |
GR32-T38-3660, T38 Guide Speed Rod, T38-Round 46-T38, Flushing Hole 17 mm |
3660 | 12 | 46 | 1 4/5 | 44.0 |
| 4148300799 |
GR32-T38-4270, T38 Guide Speed Rod, T38-Round 46-T38, Flushing Hole 17 mm |
4270 | 14 | 46 | 1 4/5 | 50.9 |
| 4148300800 |
GR32-T38-4880, T38 Guide Speed Rod, T38-Round 46-T38, Flushing Hole 17 mm |
4880 | 16 | 46 | 1 4/5 | 57.7 |
| 4148300801 |
GR32-T38-5530, T38 Guide Speed Rod, T38-Round 46-T38, Flushing Hole 17 mm |
5530 | 18 1/7 | 46 | 1 4/5 | 65.0 |
| 4148300802 |
GR32-T38-6095, T38 Guide Speed Rod, T38-Round 46-T38, Flushing Hole 17 mm |
6095 | 20 | 46 | 1 4/5 | 71.3 |
