Coal Mining Drill Shank Adapter Furukawa M120 Pd 200 Pd 200r

Coal Mining Drill Shank Adapter Furukawa M120 Pd 200 Pd 200r

Coal Mining Drill Shank Adapter Furukawa M120 Pd 200 Pd 200r
Coal Mining Drill Shank Adapter Furukawa M120 Pd 200 Pd 200r
Coal Mining Drill Shank Adapter Furukawa M120 Pd 200 Pd 200r
Product Details:
Place of Origin: China
Brand Name: MIROC
Certification: ISO
Model Number: 4148301099-4148301104
Payment & Shipping Terms:
Minimum Order Quantity: 50
Price: negotiation
Packaging Details: Wooden Plate
Delivery Time: 25 days
Payment Terms: T/T or L/C
Supply Ability: 20000 pieces per month
Contact Now
Detailed Product Description
Use: Coal Mining,Quarry Drilling Or Well Drilling Color: Request
Advantage: High Performance Name: Drill Shank Adapter Furukawa M120 Pd 200 Pd 200r
High Light:

coal mining drill shank adapter

,

high performance drill shank adapter

Description

There are two types of Sank adapters:
Male: are ideal for drifting, tunneling & extensión applications where high bending stresses are present.
Female: are used when the drilling space is limited and the total length is important.



In top hammer drilling, the shank adapter transmits impact energy from the piston to the rod(s) or tube(s). Additionally, rotation torque is delivered via the shank adapter.

• Used in top hammer drilling systems


Color: Based on Customer requirements


Material: Tungsten carbide and high strength alloy steel


Processing: CNC milling and proprietary heat treatment process


Type: Furukawa Shank Adapters


Applications

• Underground mining
• Tunneling
• Quarry


Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance


Specification

Part Number

Product Code and Brief

Description

Thread Length (mm) Weight (kg)

Flushing Hole

Size (mm)

4148301099 M 120, PD 200 [G1] R32 330 3.6 14.3
4148301100 M 120, PD 200 [G2] R38 350 3.8 14.3
4148301101 M 120, PD 200 [G3] T38 380 4 14.3
4148301102 M 120, PD 200 [G4] T38 446 4.3 14.3
4148301103 PD 200R [G1] T38 484 4 14.3
4148301104 PD 200R [G2] T45 484 4.3 14.3



Coal Mining Drill Shank Adapter Furukawa M120 Pd 200 Pd 200r 0
