Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools

Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools

  • Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools
  • Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools
  • Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools
Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools
Product Details:
Place of Origin: China
Brand Name: KSQ
Certification: ISO 9001
Model Number: Tapered Rock Drilling Button Bit
Payment & Shipping Terms:
Minimum Order Quantity: 10 Pieces
Price: Negotiable
Packaging Details: Carton Box or Wooden Box
Delivery Time: 25 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 Pieces Per Month
Contact Now
Detailed Product Description
Type: Short/long Skirt; Cross-type Button Bit Shape: Spherical, Ballistic
Material: Tungsten Carbide Application: Mining Operations, Tunneling, Quarrying, Construction
Colors: Green, Black, Based On Request MOQ: 1 PCS
Taper: 7° Weight, Kg: 0.29 - 1.19
High Light:

type 7 degree cross bit

,

tapered drilling cross bit

,

mining tapered bit

Type 7 Degree Mining Operations Tapered Drilling Tools Cross Bit



Product Introduction:

Tapered Rock Drill Bits have three types: taper chisel bit, taper cross bit and taper button bit. It's suitable for H22mm andH25mm taper rock drill rods. It has three taper degree: 7°, 11°, 12°. It's widely used for hard rock(f=8~18) drilling use.Taper cross bits is a hot sales product.
Taper Cross Bits:
1) Tapered connection: 7,11,12
2) Chisel bit diameter: 30-60mm
3) Technology:hot-pressing or welding
4) Bit Body: Short skirt and Long skirt
5) Tapered drill rod: H22/H25*108mm

Length (mm)
Chisel Size (H x W) mm
Weight (Kg)
1
30
12x12x8
0.29
2
32
12x12x8
0.31
3
33
12x12x8
0.33
4
34
12x12x8
0.34
5
35
12x12x8
0.36
6
36
13x12x8
0.37
7
38
14x12x8
0.43
8
40
15x12x8
0.47
9
41
15x12x8
0.49
10
42
15x12x8
0.51
11
43
15x12x8
0.53
12
45
17x14x8
0.58
13
48
17x14x8
0.67
14
50
19x14x8
0.72
15
55
20x16x10
0.92
16
60
20x16x10
1.19



Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools 0

Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools 1

Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools 2Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools 3Type 7 Degree Cross Bit Mining Operations Tapered Drilling Tools 4
