Name: API Standard DTH Drill Rods Drill Pipe For Water Well Drilling And Rock Blasting
Brand: MIRCO
SKU: DTH Drill rod
Rating: 4.6 (134 reviews)

Home Products Drill Coupling

API Standard DTH Drill Rods Drill Pipe For Water Well Drilling And Rock Blasting

Product Details:

Place of Origin:	China
Brand Name:	MIRCO
Model Number:	DTH Drill rod

Payment & Shipping Terms:

Minimum Order Quantity:	negociated one
Price:	negociated one
Packaging Details:	no package
Delivery Time:	10-15 days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	100000 Piece/Pieces per Month

Contact Now

Detailed Product Description

Product Name:	DTH Drill Rod	Type:	Drill Pipe
Machine Type:	Drilling Tool	Material:	Carbon Steel, S135,R780,DZ50
Processing Type:	Forging	Use:	Rock Drilling/Water Well Mining
Length:	500~8000mm	Thread Standard:	API Standard
Pipe Thread:	2 3/8''API REG
High Light:	API Standard Rods Drill Pipe , Water Well Rods Drill Pipe , Rock Blasting Rods Drill Pipe

API Standard DTH Drill Rods Drill Pipe For Water Well Drilling And Rock Blasting

DTH Drill rod

DTH Drill rods that are used in applications such as DTH/ DTHR/ DR basically comprise of a steel tube with a pin at one end and a box on the other. The job of the drill pipe is to transmit rotational torque and thrust from the drill rig rotary head to down hole drilling tools.

DTH drill rods are used for connecting DTH hammer and DTH button bits; they are made from seamless tubes. Rods play a significant role in all DTH drilling, regardless of application, rock type, hole depth or drill rig. The key features of a high quality DTH rod are durability, accuracy and manageability. According to different application, different diameters of drill tubes are needed, basically, smaller DTH hammers need smaller DTH drill tubes, vice avers. Usually we are offering 50mm, 60mm, 76mm, 89mm, etc. ALL DTH drill rods are friction welded, and usually the threads are standard API connections,like23/8" API REG thread, 3 1/2" API REG thread or API IF thread, etc. According to customers request, from 1000mm to 5000mm length of rods are available.

Standard DTH Drill Pipe Specification

Diameter (mm)	Diameter (in)	Wall (mm)	Wall (in)	Length (mm)	Length (ft)	Box Thread	Pin Thread	Wrench Flat Width (mm)	Wrench Flat Width (in)	Unit Weight (kg)	Unit Weight (lb)
76	3.00	4	0.157	1000	3.28	2 3/8" API	2 3/8" API	A/F65	2.5	12	26
76	3.00	6.3	0.248	1000	3.28	2 3/8" API	2 3/8" API	A/F65	2.5	17	37
76	3.00	8.8	0.248	1000	3.28	2 3/8" API	2 3/8" API	A/F65	2.5	17	37
76	3.00	4	0.157	1500	4.92	RD50-6	RD50-6	A/F65	2.5	16	35
76	3.00	4	0.157	1500	4.92	2 3/8" API	2 3/8" API	A/F65	2.5	16	35
76	3.00	6.3	0.248	1500	4.92	2 3/8" API	2 3/8" API	A/F65	2.5	23	51
76	3.00	8.8	0.346	1500	4.92	2 3/8" API	2 3/8" API	A/F65	2.5	24	53
76	3.00	8.8	0.346	1800	5.91	2 3/8" API	2 3/8" API	A/F65	2.5	28	62
76	3.00	4	0.157	2000	6.56	2 3/8" API	2 3/8" API	A/F65	2.5	19	42
76	3.00	6.3	0.248	2000	6.56	2 3/8" API	2 3/8" API	A/F65	2.5	28	62
76	3.00	8.8	0.346	2000	6.56	2 3/8" API	2 3/8" API	A/F65	2.5	32	71
76	3.00	8.8	0.346	2000	6.56	2 3/8" API	2 3/8" API	A/F65	2.5	32	71
76	3.00	4	0.157	3000	9.84	RD50-6	RD50-6	A/F65	2.5	24	53
76	3.00	6.3	0.248	3000	9.84	RD50-6	RD50-6	A/F65	2.5	39	86
76	3.00	6.3	0.248	3000	9.84	2 3/8" API	2 3/8" API	A/F65	2.5	39	86
76	3.00	4	0.157	3000	9.84	2 3/8" API	2 3/8" API	A/F65	2.5	25	55
76	3.00	4	0.157	3000	9.84	2 3/8" API	2 3/8" API	A/F65	2.5	25	55
76	3.00	6.3	0.248	3720	12.20	2 3/8" API	2 3/8" API	A/F65	2.5	44	97
76	3.00	6.3	0.248	4000	13.12	2 3/8" API	2 3/8" API	A/F65	2.5	49	108
76	3.00	4	0.157	4000	13.12	2 3/8" API	2 3/8" API	A/F65	2.5	31	68
76	3.00	6.3	0.248	4500	14.76	2 3/8" API	2 3/8" API	A/F65	2.5	52	115
76	3.00	6.3	0.248	5000	16.40	2 3/8" API	2 3/8" API	A/F65	2.5	61	134
76	3.00	6.3	0.248	6000	19.69	2 3/8" API	2 3/8" API	A/F65	2.5	72	159
76	3.00	6.3	0.248	6000	19.69	2 3/8" API	2 3/8" API	A/F65	2.5	70	154
89	3.50	4	0.157	1000	3.28	2 3/8" API	2 3/8" API	A/F65	2.5	13	29
89	3.50	6.3	0.248	1000	3.28	2 3/8" API	2 3/8" API	A/F65	2.5	17	37
89	3.50	6.3	0.248	1000	3.28	2 3/8" IF	2 3/8" IF	A/F65	2.5	17	37
89	3.50	4	0.157	1500	4.92	2 3/8" API	2 3/8" API	A/F65	2.5	18	40
89	3.50	4	0.157	1500	4.92	2 3/8" IF	2 3/8" IF	A/F65	2.5	18	40
89	3.50	6.3	0.248	1500	4.92	2 3/8" API	2 3/8" API	A/F65	2.5	24	53
89	3.50	6.3	0.248	1500	4.92	2 3/8" IF	2 3/8" IF	A/F65	2.5	24	53
89	3.50	6.3	0.248	1700	5.58	2 3/8" API	2 3/8" API	A/F65	2.5	28	62
89	3.50	4	0.157	1800	5.91	2 3/8" API	2 3/8" API	A/F65	2.5	20	44
89	3.50	6.3	0.248	1800	5.91	2 3/8" API	2 3/8" API	A/F65	2.5	29	64
89	3.50	8.8	0.346	1800	5.91	2 3/8" API	2 3/8" API	A/F65	2.5	33	73
89	3.50	8.8	0.346	1950	6.40	2 3/8" API	2 3/8" API	A/F65	2.5	34	75
89	3.50	4	0.157	2000	6.56	2 3/8" API	2 3/8" API	A/F65	2.5	22	49
89	3.50	4	0.157	2000	6.56	2 3/8" IF	2 3/8" IF	A/F65	2.5	22	49
89	3.50	6.3	0.248	2000	6.56	2 3/8" API	2 3/8" API	A/F65	2.5	30	66
89	3.50	6.3	0.248	2000	6.56	2 3/8" IF	2 3/8" IF	A/F65	2.5	30	66
89	3.50	8.8	0.346	2000	6.56	2 3/8" API	2 3/8" API	A/F65	2.5	38	84
89	3.50	6.3	0.248	2100	6.89	2 3/8" API	2 3/8" API	A/F65	2.5	31	68
89	3.50	4	0.157	3000	9.84	2 3/8" API	2 3/8" API	A/F65	2.5	28	62
89	3.50	4	0.157	3000	9.84	2 3/8" IF	2 3/8" IF	A/F65	2.5	28	62
89	3.50	6.3	0.248	3000	9.84	RD70-4	RD70-4	A/F65	2.5	43	95
89	3.50	6.3	0.248	3000	9.84	2 3/8" API	2 3/8" API	A/F65	2.5	43	95
89	3.50	6.3	0.248	3000	9.84	2 3/8" IF	2 3/8" IF	A/F65	2.5	43	95
89	3.50	8.8	0.346	3000	9.84	2 3/8" API	2 3/8" API	A/F65	2.5	52	115
89	3.50	6.3	0.248	3000	9.84	2 3/8" IF	2 3/8" IF	A/F65	2.5	43	95
89	3.50	4	0.157	3000	9.84	2 3/8" API	2 3/8" API	A/F65	2.5	30	66
89	3.50	6.3	0.248	4000	13.12	2 3/8" API	2 3/8" API	A/F65	2.5	56	123
89	3.50	4	0.157	4000	13.12	2 3/8" API	2 3/8" API	A/F65	2.5	39	86
89	3.50	6.3	0.248	4500	14.76	2 3/8" API	2 3/8" API	A/F65	2.5	74	163
89	3.50	4	0.157	4500	14.76	2 3/8" API	2 3/8" API	A/F65	2.5	37	82
89	3.50	6.3	0.248	5000	16.40	2 3/8" API	2 3/8" API	A/F65	2.5	69	152
89	3.50	6.3	0.248	6000	19.69	2 3/8" API	2 3/8" API	A/F65	2.5	81	179
89	3.50	8.8	0.346	6000	19.69	2 3/8" API	2 3/8" API	A/F65	2.5	99	218
102	4.50	8.8	0.346	1000	3.28	2 3/8" IF	2 3/8" IF	A/F75	3	28	61
102	4.50	6.3	0.248	1700	5.58	2 3/8" IF	2 3/8" IF	A/F75	3	36	79
102	4.50	6.3	0.248	3000	9.84	2 7/8" API	2 7/8" API	A/F75	3	55	121
102	4.50	8.8	0.346	3000	9.84	2 3/8" API	2 3/8" API	A/F75	3	94	206
102	4.50	8.8	0.346	3000	9.84	2 3/8" IF	2 3/8" IF	A/F75	3	94	206
102	4.50	6.3	0.248	4000	13.12	2 7/8" API	2 7/8" API	A/F75	3	70	154
102	4.50	6.3	0.248	4000	13.12	3 1/2" API	3 1/2" API	A/F75	3	70	154
102	4.50	6.3	0.248	5000	16.40	3 1/2" API	3 1/2" API	A/F65	3	85	187
102	4.50	6.3	0.248	5000	16.40	2 7/8" API	2 7/8" API	A/F75	3	85	187
102	4.50	6.3	0.248	6000	19.69	2 7/8" API	2 7/8" API	A/F75	3	100	220
102	4.50	6.3	0.248	6000	19.69	3 1/2" API	3 1/2" API	A/F75	3	100	220
102	4.50	6.3	0.248	6000	19.69	2 7/8" IF	2 7/8" IF	A/F75	3	100	220
114	4.50	12.7	0.500	1219	4.00	3 1/2" API	3 1/2" API	A/F75	3	48	105
114	4.50	12.7	0.500	1219	4.00	3 1/2" API	3" BECO	A/F75	3	48	105
114	4.50	12.7	0.500	2133	7.00	3 1/2" API	3 1/2" API	A/F75	3	61	135
114	4.50	17	0.670	6000	19.69	3" BECO	3" BECO	A/F90	3.5	266	585
114	4.50	6.3	0.248	1000	3.28	3 1/2" API	3 1/2" API	A/F95	3.75	26	57
114	4.50	8.8	0.346	1000	3.28	3 1/2" API	3 1/2" API	A/F95	3.75	31	68
114	4.50	6.3	0.248	1500	4.92	2 3/8" IF	2 7/8" IF	A/F95	3.75	35	77
114	4.50	6.3	0.248	1500	4.92	3 1/2" API	3 1/2" API	A/F95	3.75	35	77
114	4.50	8.8	0.346	1500	4.92	3 1/2" API	3 1/2" API	A/F95	3.75	42	93
114	4.50	6.3	0.248	1500	4.92	2 3/8" API	2 3/8" API	A/F95	3.75	35	77
114	4.50	6.3	0.248	2000	6.56	3 1/2" API	3 1/2" API	A/F95	3.75	43	95
114	4.50	6.3	0.248	2000	6.56	3 1/2" IF	3 1/2" IF	A/F95	3.75	43	95
114	4.50	8.8	0.346	2000	6.56	3 1/2" API	3 1/2" API	A/F95	3.75	54	119
114	4.50	6.3	0.248	3000	9.84	3 1/2" API	3 1/2" API	A/F95	3.75	60	132
114	4.50	6.3	0.248	3000	9.84	3 1/2" IF	3 1/2" IF	A/F95	3.75	60	132
114	4.50	8.8	0.346	3000	9.84	3 1/2" API	3 1/2" API	A/F95	3.75	77	170
114	4.50	8.8	0.346	4000	13.12	3 1/2" API	3 1/2" API	A/F95	3.75	100	220
114	4.50	6.3	0.248	4000	13.12	3 1/2" API	3 1/2" API	A/F95	3.75	76	168
114	4.50	6.3	0.248	4500	14.76	3 1/2" API	3 1/2" API	A/F95	3.75	96	211
114	4.50	8.8	0.346	4500	14.76	3 1/2" API	3 1/2" API	A/F95	3.75	111	245
114	4.50	6.3	0.248	5000	16.40	3 1/2" API	3 1/2" API	A/F95	3.75	93	205
114	4.50	6.3	0.248	5000	16.40	3 1/2" IF	3 1/2" IF	A/F95	3.75	94	207
114	4.50	8.8	0.346	5000	16.40	3 1/2" API	3 1/2" API	A/F95	3.75	122	269
114	4.50	6.3	0.248	6000	19.69	3 1/2" API	3 1/2" API	A/F95	3.75	110	243
114	4.50	8.8	0.346	6000	19.69	3 1/2" API	3 1/2" API	A/F95	3.75	136	300
114	4.50	12.7	0.500	6000	19.69	3 1/2" API	3 1/2" API	A/F95	3.75	200	440
114	4.50	8.8	0.346	6000	19.69	2 7/8" API	2 7/8" API	A/F95	3.75	145	320
114	4.50	8.8	0.346	6000	19.69	NC35	NC35	A/F95	3.75	145	320
127	5.00	8.8	0.346	2000	6.56	3 1/2" API	3 1/2" API	A/F95	3.75	64	141
127	5.00	6.3	0.248	2000	6.56	3 1/2" API	3 1/2" API	A/F95	3.75	52	115
127	5.00	6.3	0.248	3000	9.84	3 1/2" API	3 1/2" API	A/F95	3.75	61	134
127	5.00	8.8	0.346	3000	9.84	3 1/2" API	3 1/2" API	A/F95	3.75	90	198
127	5.00	6.3	0.248	6000	19.69	3 1/2" API	3 1/2" API	A/F95	3.75	127	280
140	5.50	8.8	0.346	1000	3.28	4 1/2" API	4 1/2" API	A/F120	4.75	45	99
140	5.50	12.7	0.500	1000	3.28	4 1/2" API	4 1/2" API	A/F120	4.75	57	125
140	5.50	8.8	0.346	1500	4.92	4 1/2" API	4 1/2" API	A/F120	4.75	48	106
140	5.50	8.8	0.346	1500	4.92	3 1/2" API	3 1/2" API	A/F120	4.75	48	106
140	5.50	6.3	0.248	1500	4.92	3 1/2" API	3 1/2" API	A/F120	4.75	43	95
140	5.50	8.8	0.346	1524	5	3 1/2" IF	3 1/2" IF	A/F120	4.75	48	106
140	5.50	8.8	0.346	2000	6.56	4 1/2" API	4 1/2" API	A/F120	4.75	76	168
140	5.50	8.8	0.346	2000	6.56	3 1/2" API	3 1/2" API	A/F120	4.75	76	168
140	5.50	12.7	0.500	2000	6.56	4 1/2" API	4 1/2" API	A/F120	4.75	114	250
140	5.50	8.8	0.346	3000	9.84	4 1/2" API	4 1/2" API	A/F120	4.75	104	229
140	5.50	8.8	0.346	3000	9.84	3 1/2" API	3 1/2" API	A/F120	4.75	104	229
140	5.50	8.8	0.346	4000	13.12	3 1/2" API	3 1/2" API	A/F120	4.75	131	289
140	5.50	8.8	0.346	5000	16.40	4 1/2" API	4 1/2" API	A/F120	4.75	160	353
140	5.50	8.8	0.346	6000	19.69	4 1/2" API	4 1/2" API	A/F120	4.75	187	412
140	5.50	8.8	0.346	6000	19.69	3 1/2" API	3 1/2" API	A/F120	4.75	187	412
