| Place of Origin: | ShanDong, China(Mainland) |
| Brand Name: | MIROC |
| Certification: | GB / API / ISO |
| Model Number: | Button bits |
| Minimum Order Quantity: | 10 pieces |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden Box or Based on Customers |
| Delivery Time: | 1-15 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 900000 pieces per month |
| Diameter: | 32mm - 42mm | Processing Type: | Hear - Precess |
|---|---|---|---|
| Use: | Mining And Construction | Material: | 42CrMo |
| Machine Type: | Drilling Tools | Connection: | H19, H22, H25 Drill Rod |
| Bit Body: | Long - Skirt, Short - Skirt | Degree: | 4, 7, 11, 12 |
| High Light: | rock drill tools,mining drilling tools |
||
Tapered Rock Drilling Tools Chisel / Cross / Button Bit for Ore Mining
Tapered Bit
It possess of high wear resistance like diamond, at the same time the impact
resistance like hard alloy and that’s made it the best material as a drill bit cutter.
Reinforced PDC has higher dense diamondpowder, claw hard alloy substrate made
the two layers solid as whole one. So, the reinforced PDC of chengtan wear
resistance, longer service life and high efficiency.Chisel bits are widely used in tunneling and mining.To meet your requirements,we provide various specification for
different rock conditions,which can improving the efficiency.
With superior carbide,special solder and good welding,our chisel bits can avoid
carbide drop off in circulsrly use.And also the bit bodies enjoy a longer life after
harden itself by heat treatment.
Taper Chisel Bits:
1) Tapered connection: 7,11,12
2) Alloy steel:42CrMo
3) Suitable carbide tips:YK20
4) Chisel bit diameter: 30-80mm
5)Technology:hot-pressing or welding
| Length (mm) | Chisel Size (H x W) mm | Weight (Kg) | |||
| 1 | 26 | 10x7 | 0.17 | ||
| 2 | 28 | 10x7 | 0.18 | ||
| 3 | 30 | 13.5x8 | 0.22 | ||
| 4 | 32 | 13.5x8 | 0.24 | ||
| 5 | 34 | 13.5x8 | 0.27 | ||
| 6 | 36 | 13.5x8 | 0.3 | ||
| 7 | 38 | 13.5x8 | 0.33 | ||
| 8 | 38 | 15x9 | 0.33 | ||
| 9 | 40 | 3.5x9.2 | 0.38 | ||
| 10 | 40 | 15x9.8 | 0.38 | ||
| 11 | 42 | 13.5x9.2 | 0.41 | ||
| 12 | 42 | 15x9.8 | 0.41 | ||
| 13 | 43 | 13.5x9.2 | 0.42 | ||
Taper Button Bits:
1) Type: Taper button bits
2) Shank Hex.Size: 22mm,25mm
3) Diameter: 30-42mm.
4) Taper degree: 7°11°12°
5) Buttons quantity: 4, 5, 6, 7, 8
6) Package: Plastic case, wooden case.
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 32 | 1x8 | 3x8 | 1 | 1 | 0.24 |
| 2 | 33 | 2x7 | 5x7 | 2 | 1 | 0.26 |
| 3 | 34 | 2x7 | 4x7 | 1 | 1 | 0.29 |
| 4 | 35 | 2x7 | 5x8 | 1 | 1 | 0.33 |
| 5 | 36 | 2x7 | 5x8 | 1 | 1 | 0.37 |
| 6 | 38 | 1x8 | 3x9 | 1 | 1 | 0.37 |
| 7 | 40 | 1x8 | 3x9 | 1 | 1 | 0.38 |
| 8 | 41 | 2x7 | 5x9 | 1 | 1 | 0.42 |
| 9 | 42 | 2x8 | 5x9 | 1 | 1 | 0.43 |
Taper Cross Bits:
1) Tapered connection: 7,11,12
2) Chisel bit diameter: 30-60mm
3) Technology:hot-pressing or welding
4) Bit Body: Short skirt and Long skirt
5) Tapered drill rod: H22/H25*108mm
| Length (mm) | Chisel Size (H x W) mm | Weight (Kg) | |||
| 1 | 30 | 12x12x8 | 0.29 | ||
| 2 | 32 | 12x12x8 | 0.31 | ||
| 3 | 33 | 12x12x8 | 0.33 | ||
| 4 | 34 | 12x12x8 | 0.34 | ||
| 5 | 35 | 12x12x8 | 0.36 | ||
| 6 | 36 | 13x12x8 | 0.37 | ||
| 7 | 38 | 14x12x8 | 0.43 | ||
| 8 | 40 | 15x12x8 | 0.47 | ||
| 9 | 41 | 15x12x8 | 0.49 | ||
| 10 | 42 | 15x12x8 | 0.51 | ||
| 11 | 43 | 15x12x8 | 0.53 | ||
| 12 | 45 | 17x14x8 | 0.58 | ||
| 13 | 48 | 17x14x8 | 0.67 | ||
| 14 | 50 | 19x14x8 | 0.72 | ||
| 15 | 55 | 20x16x10 | 0.92 | ||
| 16 | 60 | 20x16x10 | 1.19 | ||
