Name: Slide Block Casing System DHD360 194mm Overburden Drilling Casing Advancer System
Brand: KSQ Technologies (Beijing) Co. Ltd
SKU: DHD360 194mm
Price: 1100 USD
Availability: InStock

Home Products Rock Drilling Tools

Slide Block Casing System DHD360 194mm Overburden Drilling Casing Advancer System

Product Details:

Place of Origin:	CHINA
Brand Name:	MIROC
Certification:	ISO
Model Number:	DHD360 194mm

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	＄1100
Delivery Time:	7-14
Supply Ability:	3000

Contact Now

Detailed Product Description

Features:	Wear Resistant High Efficiency Stable Performance	Product Name:	Slide Block Casing System
Model:	DHD360	Outer Diameter:	194mm
Product Type:	Casing Advancer System	Drilling Method:	Overburden Drilling
Application:	Foundation Drilling Mining Geotechnical Engineering	Compatible Equipment:	DTH Drilling System
Material:	High Strength Alloy Steel	Connection Type:	Customized According To Requirements
Processing Type:	CNC Machining Heat Treatment	Service:	OEM ODM Customization Available
Packaging:	Standard Export Packaging	Delivery:	According To Order Quantity
Highlight:	DHD360 overburden drilling casing system , 194mm slide block casing advancer , rock drilling casing system

DHD360 194mm Slide Block Casing System for Overburden Drilling

The DHD360 194mm Slide Block Casing System is engineered for overburden drilling applications across mining, foundation construction, geotechnical engineering, and other challenging ground conditions. It supports efficient drilling and casing advancement in loose soil, gravel, weathered rock, fractured formations, and unstable overburden layers.

Featuring a robust slide block structure and precision-machined components, this casing system delivers reliable engagement, stable operation, and effective force transmission during drilling. Its heavy-duty construction withstands demanding working conditions, while the wear-resistant surface treatment contributes to extended service life and reduced maintenance requirements.

The 194mm configuration is suitable for drilling projects requiring dependable borehole support and efficient casing installation. By advancing the casing during the drilling process, the system helps reduce the risk of borehole collapse, maintain hole integrity, and improve operational efficiency in difficult formations.

The DHD360 Slide Block Casing System can be supplied for compatible drilling equipment and customized according to project specifications, connection requirements, and operating conditions. It is an ideal solution for contractors seeking durable drilling components for overburden drilling, ground stabilization, and foundation engineering projects.

Slide Block Casing System Specifications

Model	(mm) Casing OD	(mm) Maximum OD of Center Bit	(mm) Casing Shoe ID	(mm) Maximum OD of Reaming	(Inch) Hammer Type
146 Slide Block Casing	φ146	φ123	φ115	φ156	4
168 Slide Block Casing	φ168	φ146	φ140	φ185	5
178 Slide Block Casing	φ178	φ156	φ150	φ193	5
183 Slide Block Casing	φ183	φ160	φ154	φ193	5
194 Slide Block Casing	φ194	φ178	φ166	φ211	6
219 Slide Block Casing	φ219	φ203	φ193	φ237	6~7
245 Slide Block Casing	φ245	φ220	φ210	φ260	6~8
273 Slide Block Casing	φ273	φ251	φ241	φ308	8
325 Slide Block Casing	φ325	φ298	φ281	φ378	8~10
377 Slide Block Casing	φ377	φ350	φ335	φ430	10~12
406 Slide Block Casing	φ406	φ380	φ363	φ426	12
560 Slide Block Casing	φ560	φ530	φ511	φ590	18
610 Slide Block Casing	φ610	φ582	φ556	φ640	18

Applications

Mining Exploration
Geotechnical Drilling
Foundation Construction
Overburden Drilling
Ground Stabilization
Drilling in Loose or Unstable Formations

Core Selling Points

Simultaneous Drilling And Casing: Improves drilling efficiency in overburden formations.
Borehole Stability: Helps prevent hole collapse in loose and unstable ground.
Wear Resistant Construction: Designed for demanding drilling environments.
Reliable Performance: Supports stable casing advancement and drilling operations.
Customizable Solutions: Dimensions and connections can be tailored to project requirements.

Product Gallery
