| Place of Origin: | China |
| Brand Name: | MIROC |
| Model Number: | RL-4 Load-Haul-Dump Machine |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Delivery Time: | 1-3 Months |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 3 Units per month |
| Highlight: | lhd load haul dump,load haul dump truck |
||
|---|---|---|---|
4 Drive Load Haul Dump Mining Loaders Underground LHD Machines
Description
The trusted workhorse of miners and tunneling professionals, the RL-4 Load-Haul-Dump
Machine is ideal for medium to large size rock excavation operations. The RL-4 maintains
the simple yet very robust design tenets of what a mining equipment should be.
Ideal for medium to large size mining/tunneling operations requiring trackless loading and
hauling equipment for moving ore and debris
DEUTZ or CUMMINS engine, combined with best-in-class catalytic exhaust and silencer system
DANA SPICER OFF-HIGHWAY transmission and torque converter
DANA SPICER OFF-HIGHWAY axles POSI-STOP service brakes
Color: Based on Customer requirements
Type: RL-4 Load-Haul-Dump Machine
Applications
Underground Mining
Hydropower Tunneling
Roadway/Railway Tunneling
Competitive Advantage
Major components from industry respected suppliers
Simple yet very robust design
Very competitive pricing compared to its counterparts coming from well-known brands
Competitive delivery
specification
| Main Dimensions | |
| Lengh | 9690mm |
| Width | 2550mm |
| Height | 2395mm |
| Wheelbase | 3500mm |
| Tread | 1940mm |
| Bucket Capacity (SAE, Heaped) | 4.3m3 |
| Bucket | |
| Type | Heavy Duty Rock Bucket |
| Bucket Arm System | Z-Bar Linkage |
| Maximum Lift Height | 5155mm |
| Maximum Dumping Height | 1500mm |
| Dumping Height Clearance | 3574mm |
| Dumping Angle | 40°±2° |
