Name: GT60-140mm Retrac Button Bit Rock Tools for Drilling&Tunneling Price
Brand: KSQ Technologies (Beijing) Co. Ltd
SKU: GT60-140mm
Price: 508.50 USD
Availability: InStock

Home Products Rock Drilling Tools

GT60-140mm Retrac Button Bit Rock Tools for Drilling&Tunneling Price

Product Details:

Place of Origin:	CHINA
Brand Name:	MIROC
Certification:	ISO
Model Number:	GT60-140mm

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	20-30
Supply Ability:	3000

Contact Now

Detailed Product Description

Thread:	GT60	Diameter:	140mm
Skirt Design:	Retrac	Carbide Design:	Dome, Ballistic, Semi-ballistic/parabolic
Surface Treatment:	Painting	Material:	Alloy Steel & Tungsten Carbides

Product Description

1. Application: The thread drill bits are widely used in metallurgy mine, geological exploration, water conservancy construction, electricity, traffic, tunnel, quarry, national defence stone project etc.
2. Material: Thread Drill bits are made by high quality alloy steel bar and tungsten carbides. Through heat
treatment, our drilling tools are tough enough to meet rock drilling demands and have the least loss of energy while drilling the rocks.
3. OEM: In addition, we can design customized thread button drill bits according to different drilling application, and
custom drill bits are applicable to drill soft rock, loose-medium rock and hard rock.

Head diameter:140mm
Thread: GT60
Angle : 35°

Button bit design: Flat face, drop centre, Normal and Retrac body.

Tungsten carbide (Buttons): Spherical, Ballistic and Conical.

Applications: Drifting and Tunneling

Specification
Diameter(mm)	Thread Type	No*Button diameter(mm)		Face	Weight(kg)
Diameter(mm)	Thread Type	Gauge	Front	Face	Weight(kg)
Standard Type
64	R32,T38	6*11	4*10	Flat	1.6
76	R32,T38,T45	6*12	4*11	Flat	2.6
89	T38,T45,T51	8*12	412+211	Flat	3.4
95	GT60	8*12	7*11	Flat	5.6
102	T45,T51,GT60	8*13	7*12	Flat	5.6
115	T45,T51,GT60	9*13	10*11	Flat	6.3
127	T51,GT60	9*14	10*13	Flat	6.5
140	T51,GT60	9*16	10*14	Flat	9.4
Retrac Type
76	T38,T45	6*12	4*11	Flat	4.4
89	T38,T45,T51	8*12	4812+2*11	Flat	5.6
102	T45,T51,GT60	8*13	7*12	Flat	5.8
115	T45,T51,GT60	9*13	10*11	Flat	9.5
127	T51,GT60	9*14	10*13	Flat	10.4
140	T51,GT60	9*16	10*14	Flat	14.4
152	GT60	9*16	11*14	Flat	22

Characteristic
(1)Bit body : normal type and retrac type
(2)R thread: R22 R25 R28 R32 R38
(3)T thread: T38 T45 T51 ST58 ST68 GT60
(4)Bit diameter: 32-127mm.
(5)Drill bit models: cross bit/button bit
(6)Button bit shape: spherical/parabolic
(7)Bit face shape: flat face and drop centre

GT60-140mm Retrac Button Bit Rock Tools for Drilling&Tunneling Price 0

GT60-140mm Retrac Button Bit Rock Tools for Drilling&Tunneling Price 1

GT60-140mm Retrac Button Bit Rock Tools for Drilling&Tunneling Price 2
